Airtac SAID80 Double Rod Cylinder SAID80X115S
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X115S Double Rod Cylinder Technical Details
- Model: SAID80X115S
- Type: ISO 15552 compliant double rod cylinder
- Bore size: Ø80 mm
- Stroke: 115 mm (adjustable cushioning)
- Operating pressure: 0.05–1.0 MPa
- Piston rod diameter: Ø25 mm (both ends)
- Rod thread: M16×1.5 (both rods)
- Port size: G3/8 (NPT1/2 optional)
- Seal material: Polyurethane (NBR optional)
- Temperature range: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Mounting style: Basic type (no built-in mounts)
- Weight: 3.6 kg (without accessories)
- Dimensions: 250mm(L) × 88mm(W) × 88mm(H)
- Cushioning: Adjustable air cushion (both ends)
- ISO standard: 15552 (formerly ISO 6431)
High-rigidity double rod cylinder featuring symmetrical force output and position detection capability. The through-rod design ensures identical velocity/power in both directions, with hardened chrome-plated rods (HRC 45-50) resisting side loads. Integrated magnet slots (T-slot design) support multiple sensor mounting options.
- Precision web tensioning systems in printing machines
- Vertical lifting mechanisms with counterbalance control
- Automated pallet clamping/unclamping operations
- Parallel gripper actuation in robotic workcells
- Plastic injection molding ejector systems
Installation recommendation:
For vertical installations exceeding 45° angle, use rod-end support brackets (ASM80-02).
Lubricate with ISO VG32 hydraulic oil if operating below 0.3 MPa. Maximum permissible
lateral load: 180N at full extension.
| Property | Property Value |
|---|---|
| sku | SAID80X115S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | 115mm |
