Airtac SAID80 Double Rod Cylinder SAID80X125S
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X125S Twin Rod Cylinder Technical Specifications
- Model: SAID80X125S
- Type: ISO 6432 standard twin rod cylinder
- Bore size: Ø80 mm (±0.13mm tolerance)
- Stroke: 125 mm (customizable 25-500mm)
- Operating pressure: 0.1-0.9 MPa
- Cushioning type: Adjustable buffer at both ends
- Piston rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Anodized aluminum alloy (6063-T5)
- Seal material: Nitrile rubber (NBR) + Polyurethane (PU)
- Mounting options: MF1 front flange, MB1 rear flange, or MP4 foot mount
- Weight: 5.8 kg (bare cylinder), 6.3 kg (with standard accessories)
- Dimensions: 400mm(L) × 112mm(W) × 112mm(H)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (recommended ISO VG32 oil for maintenance)
- Protection rating: IP40 (IP67 with optional wiper seal)
- Max thrust: 4520N at 0.63MPa (theoretical value)
- Air consumption: 6.3L per cycle (single stroke)
High-rigidity twin piston rod cylinder designed for precision linear motion systems requiring enhanced lateral load capacity. The dual-rod configuration minimizes rotational deflection during operation (≤0.5° at max load), making it ideal for applications demanding precise positional accuracy. Features corrosion-resistant construction with 15μm hard anodized surface treatment.
- Automated assembly line positioning mechanisms
- Die-casting machine core-pulling systems
- Glass processing equipment clamping devices
- Precision material handling robots
- Automotive welding fixture actuators
Installation guidelines:
Maintain ≤0.1mm/m alignment tolerance during mounting. Use flexible couplings
when connecting to guided slides. For vertical installations, specify "V" orientation
code to enable upgraded rod seal configuration. Allow 15mm minimum clearance
for magnetic switch installation.
- SM-8N magnetic sensor (IP67 rated)
- CM-L80 auto adjustable cushion kit
- RPD80-125S rod lock module
- Heat-resistant seal kit (up to 150℃)
| Property | Property Value |
|---|---|
| sku | SAID80X125S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | 125mm |
