Airtac SAID80 Double Rod Cylinder SAID80X130S
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X130S Dual Rod Cylinder Specifications
- Model: SAID80X130S
- Type: Double rod cylinder (ISO 15552 standard)
- Bore size: 80 mm
- Stroke: 130 mm (±1.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Piston rod diameter: 20 mm × 2 (dual rods)
- Cushioning: Adjustable air cushion at both ends
- Mounting options: Basic type (no flange), MF1/MF2 front flange
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Repeat positioning accuracy: ±0.5 mm
- Weight: 5.2 kg (without accessories)
- Dimensions: 286mm(L) × 80mm(Bore Ø) × 96mm(H) (H: center distance between rods)
- Rod stroke tolerance: +2.0mm/-0mm
- Max lateral load: 180 N at mid-stroke
- Port size: G1/2 (ISO 1179)
High-rigidity dual rod cylinder designed for precision linear motion requiring enhanced moment resistance. Features symmetrical force distribution through parallel rods and hardened chromium-plated piston rods (HRC 45-50) for wear resistance. Optional magnetic piston version (add "-M" suffix) for position sensing.
- Palletizing robot Z-axis drives
- Plastic injection molding machine ejectors
- Precision grinding machine workholding
- Automated conveyor gate actuators
- Semiconductor wafer handling systems
Installation guidelines:1. Align rod axis within 0.2mm perpendicularity tolerance
2. Use flexible couplings for eccentric loads over 50N
3. Lubricate with ISO VG32 hydraulic oil (NBR-compatible)
4. For vertical mounting, install rod-end locking nut (AN80-03 accessory)
| Property | Property Value |
|---|---|
| sku | SAID80X130S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | 130mm |
