Airtac SAID80 Double Rod Cylinder SAID80X140S
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir capability
3. Cross-reinforced aluminum profile body without tie rods ensures superior corrosion resistance. External sensor mounting grooves enable fast and convenient installation
4. Precision-engineered smooth cushion adjustment mechanism
5. Multiple cylinder specifications and mounting accessories available for flexible configuration
6. High-temperature resistant sealing materials support operational range of 0-150°C
Category: Double Rod Cylinders | Brand: AirTAC | Series: SAID80
AirTAC SAID80X140S Twin Rod Cylinder Specifications
- Model: SAID80X140S
- Type: ISO 15552 standard twin rod cylinder (double piston rod)
- Bore size: 80mm
- Stroke: 140mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable air cushion at both ends
- Piston speed: 50–800 mm/s (lubricated)
- Ambient temperature: -20℃ to 80℃
- Mounting style: Basic type (axial foot/rod flange optional)
- Port size: 1/4 NPT (G1/4 optional)
- Rod material: Chrome-plated carbon steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: Nitrile rubber (NBR) with wear-resistant ring
- Weight: 2.85kg (excluding accessories)
- Dimensions: 200mm(L) × 90mm(W) × 100mm(H) (stroke-dependent length)
- Repeat accuracy: ±0.1mm
- Magnetic sensor: Pre-installed slot for PU series sensors (not included)
High-rigidity twin rod cylinder designed for precision linear motion requiring enhanced moment resistance. Features symmetrical load distribution through dual piston rods, making it ideal for applications demanding anti-rotation stability. The through-rod design maintains consistent center of gravity during stroke movement.
- Precision palletizing robots in logistics systems
- Vertical lifting mechanisms in automotive assembly
- Glass panel transfer systems with vacuum grippers
- PCB drilling/punching machines requiring vibration control
- Multi-axis positioning stages for optical inspection
Installation tips:
Maintain parallel alignment of twin rods during mounting. Use rod-end bearings
for angular misalignment compensation. Lubricate with ISO VG32 hydraulic oil
for initial operation. Allow 5-10mm clearance behind end covers for cushion adjustment.
| Property | Property Value |
|---|---|
| sku | SAID80X140S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 80 mm |
| Stroke | <140mm> |
