Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 100mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke100 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilAC24V
- EntryTerminal
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E
The AirTAC SAIF32X100S-06E is a double-acting ISO 15552 profile cylinder with a built-in 4M210-06 5/2 solenoid valve, delivering a Cv of 0.78 and a 14.0 mm2 orifice. Driven by an AC24V terminal-entry coil consuming 3.5 VA, it activates in 0.05 s or less. The assembled unit operates at 0.15-0.8 MPa because the internal pilot valve limits the 1.0 MPa cylinder rating. At 0.5 MPa it provides 402 N of push force.
This self-contained unit eliminates remote valves and excess plumbing, making it perfect for decentralized installations across large machines. The manifold connects the valve to the cylinder via an O8 x O5 PU tube, and the valve port (1/8) differs from the cylinder port (1/8). Factory-set to retract when energised, the 5/2 valve can be repositioned to extend on signal. The included -S magnet pairs precisely with AirTAC CMSE reed and DMSE electronic sensors.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | AC24V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×100 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| E | Coil voltage AC24V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E Is Used
Decentralized Stations
Ideal for large machines with distributed stations, eliminating long tubing runs from a central control panel by switching locally via the built-in valve.
Compact Assembly Machines
Fits space-tight machinery where adding a separate valve island is impossible, providing 402 N of push force from a single coil signal.
Retrofit Automation
Perfect for upgrading existing lines where routing new pneumatic tubing for remote valves is costly and complex, simplifying control with an AC24V connection.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E the Right Choice?
Choose this 32 mm bore when compact force is needed; step up to the 40 mm bore if you require 628 N of push force at 0.5 MPa. The self-valved SAIF design beats a separate cylinder and remote valve by cutting panel space, wiring, and tubing runs. This model uses an AC24V terminal coil with PT threaded ports.
Remember that the 5/2 valve routes air but does not lock the load; for position holding, select an AirTAC SAIL lock cylinder. To replace this unit, match the 32 mm bore, 100 mm stroke, 06 valve port, AC24V terminal coil, PT threads, and the -S magnet. Since the stroke is 100 mm, no external guide is required.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X100S-06E FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N of push force and 345 N of pull force. The built-in 4M210-06 valve has an effective area of 14.0 mm2 (Cv 0.78) and operates at a maximum frequency of 5 cycles per second.
It uses a 5/2 solenoid valve that holds position via internal pilot pressure, not a spring. Factory-set to retract when the AC24V coil energizes, you can reposition the valve to extend-when-energized. This eliminates the need for a separate remote valve.
