Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F
The AirTAC Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F is a genuine double-acting ISO 15552 cylinder with a Ø32mm bore, 125mm stroke and a built-in 4M210-06 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ32 mm
- Stroke125 mm
- Built-in valve4M210-06
- Valve port1/8"
- CoilDC12V
- EntryTerminal
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F
The AirTAC SAIF32X125S-06F is a double-acting ISO 15552 profile cylinder with a built-in 4M210-06 5/2 solenoid valve, delivering a 14.0 mm2 flow (Cv 0.78). Driven by a DC12V terminal entry coil drawing 3.0 W, it eliminates the need for a separate remote valve. The cylinder body features a PT1/8 port, while the integrated valve uses a 1/8" connection, linked internally via O8xO5 PU tubing. It includes a magnet for CMSE and DMSE sensors.
Because the cylinder body rates to 1.0 MPa but the internal pilot valve operates at 0.15-0.8 MPa, the practical working range for this assembled unit is 0.15-0.8 MPa. In its factory setting, the piston rod retracts when the coil is energised, though this can be reconfigured to extend-when-energised simply by repositioning the valve. This decentralized design minimizes plumbing and panel space across large machines.
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F Technical Specifications
| Model | Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F |
|---|---|
| Series | SAIF ISO 15552 cylinder with valve |
| Bore size | Ø32 mm |
| Stroke | 125 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | G1/8 |
| Rod thread | M10×1.25 |
| PU tube | Ø8 × Ø5 |
| Built-in valve | 4M210-06 (5/2) |
|---|---|
| Valve flow | 14.0 mm² (Cv 0.78) |
| Max frequency | 5 cycle/sec |
| Coil voltage | DC12V · DC 3.0 W |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAIF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAIF datasheet. Port options: PT / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F
| SAIF | ISO 15552 cylinder with built-in 4M valve. |
|---|---|
| 32×125 | Bore × stroke in mm. |
| -06 | Valve port 1/8" → 4M210-06. |
| F | Coil voltage DC12V. |
| I / (blank) | Terminal electrical entry. |
SAIF does not hold its load without air — the valve routes air, it is not a lock. For load-holding use a SAIL (lock) or BSAI (clamp-lock).
Where the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F Is Used
Decentralized Assembly Stations
Ideal for large machines with multiple stations, using the built-in valve to minimize panel space and eliminate long remote tubing runs.
Space-Tight Electronics Handling
The compact 32mm profile combined with a DC12V terminal coil provides precise actuation in confined enclosures without external manifolds.
Retrofit Automation Upgrades
Perfect for upgrading existing machinery where adding a separate valve island is impractical, offering self-contained switching via a 5/2 valve.
Is the Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F the Right Choice?
Choose this 32mm bore when you need 345N of pull force at 0.5 MPa; stepping up to the 40mm bore provides 528N of pull, while dropping to a smaller bore is not available in this series. The SAIF32X125S-06F is ideal for space-tight machines where running separate valve tubing is costly, as one DC12V coil signal directly switches the cylinder. It operates at speeds of 30-800 mm/s.
Note that the built-in 5/2 valve routes air and is not a lock; the air cushion only decelerates near stroke end, so it will not hold a load without live pressure. For load-holding applications, consider the SAIL lock variant. When replacing this unit, verify the 125mm stroke, 1/8" valve port, DC12V voltage, PT thread, and the -S magnet requirement.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → SAIL / BSAI
Airtac SAIF Series Standard Cylinder with Valve SAIF32X125S-06F FAQ
At 0.5 MPa, this 32mm bore cylinder provides 402N of push force and 345N of pull force. The integrated 4M210-06 valve has an effective area of 14.0 mm2 (Cv 0.78) and a maximum frequency of 5 cycles per second.
It uses a 5/2 solenoid valve operating on DC12V (3.0 W). By default, the factory setting retracts the rod when the coil is energised. By repositioning the valve, you can reconfigure it to extend-when-energised, providing flexible control without needing a separate remote valve.
