Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S
The AirTAC Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø80mm bore and 1000mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke1000 mm
- Port sizeG3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S
The AirTAC SAIJ80X1000-10-S is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that creates a 990-1000 mm usable travel window for fine-tuning end positions. Delivering 4523 N of push force at 0.9 MPa, it is equipped with a SUS304 stainless steel rod for superior corrosion resistance and includes a magnet for CMSE reed and DMSE electronic sensors.
The extruded aluminum barrel incorporates sensor grooves on both sides for flexible switch mounting. While the rear adjuster and variable air cushions manage deceleration at the travel ends, this cylinder does not hold loads without live air pressure; for fail-safe load holding, consider the SAIL or BSAI series.
Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S Technical Specifications
| Model | Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S Is Used
Variable End-Stop Tuning
Dial in the exact 990 to 1000 mm retract position during machine commissioning without swapping out the entire cylinder.
Product Changeover Lines
Quickly adjust the stroke length by up to 10 mm to accommodate slight size variations in packaged goods moving along the conveyor.
Corrosive Environment Actuation
Utilize the SUS304 stainless steel rod for reliable double-acting thrust in manufacturing cells requiring high corrosion resistance.
Is the Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S the Right Cylinder?
Choose this 80 mm bore when an application requires 4523 N of thrust at 0.9 MPa, stepping up from a 63 mm bore that provides 2805 N. The 10 mm adjustable stroke is ideal for dialing in exact retract positions during machine setup or product changeovers without adding external stops.
To match this ISO 15552 cylinder, specify the 80 mm bore, 1000 mm stroke, PT tapered port threads, and the -S magnet option. Because the stroke is 1000 mm, an external guide rail is strongly recommended to prevent side-loading damage to the rod seal and bearing.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SAIJ80 Adjustable Cylinder SAIJ80BX1000-10S FAQ
The 80 mm bore provides 2513 N of push force and 2268 N of pull force at 0.5 MPa. At 0.9 MPa, the push force increases to 4523 N.
The rear adjuster acts as a stopper that allows you to shorten the effective stroke by up to 10 mm, providing a usable travel window of 990 to 1000 mm. It decelerates the travel end but does not lock or hold the load without live air pressure.
