Airtac SAILB Rear Lock Cylinder SAILB100X175S
2. Unlocking modes: Automatic and Manual.
Category: Locking Cylinders | Brand: AirTAC | Series: SAILB （Note: Professional term adjustments include "Locking Cylinder" as industry-standard terminology, "Unlocking modes" for operational clarity, and maintaining brand capitalization consistency. HTML tags preserved as requested.）
AirTAC SAILB100X175S Locking Cylinder Specifications
- Model: SAILB100X175S
- Type: Double-acting cylinder with mechanical lock
- Bore diameter: 100mm
- Stroke: 175mm
- Operating pressure: 0.05–1.0 MPa
- Lock holding force: 2,800N (at 0.5MPa)
- Lock release pressure: ≥0.3MPa
- Cushioning type: Adjustable elastic cushion
- Port size: G1/2 (NPT1/2 optional)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Weight: 4.5kg ±3%
- Dimensions: 400mm(L) × 130mm(W) × 130mm(H) (including mounts)
- Mounting style: Standard ISO/VDMA front flange (MF1) with optional foot mounting
- Protection rating: IP54 (standard seals)
Heavy-duty locking cylinder featuring fail-safe mechanical position retention during air supply interruption. Precision ground rod with dual chrome plating ensures low friction and corrosion resistance. Integrated locking mechanism activates automatically at stroke ends or any intermediate position through pressure control.
- Safety clamping in press brake operations
- Position holding in vertical lifting systems
- Emergency stop mechanisms in automated assembly lines
- Workpiece fixturing for CNC machining centers
- Elevator door locking systems
Installation note:
Ensure locking mechanism orientation matches gravity direction in vertical applications.
Lubricate with ISO VG32 hydraulic oil if using non-lubricated air.
Allow 50mm clearance behind cylinder for maintenance access.
| Property | Property Value |
|---|---|
| sku | SAILB100X175S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Type | Adjustable Cushioning |
| Bore Diameter | 100mm |
| Stroke | 175mm |
| Lock Position | Rear Cover with Lock Type |
