Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A is a genuine double-acting profile-type cylinder with a Ø100mm bore, 1000mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke1000 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilAC220V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A
The SAUF100X1000-10A is a double-acting profile cylinder with a built-in AirTAC 4M310 5/2 solenoid valve on the cap. One coil signal drives the actuator, eliminating remote plumbing and saving a manifold slot. The extruded aluminum barrel is shorter than an ISO 15552 cylinder of the same bore. This 100mm bore unit has a 1/2 inch cylinder port, a 3/8 inch valve port, and a 1000mm stroke.
Operating within the 0.15-0.8 MPa valve window, it delivers 3927 N push force at 0.5 MPa. The 4M310-10 valve provides 30 mm2 flow (Cv 1.68) at up to 4 cycles per second. The AC220V terminal entry coil is IP65 rated. Based on the 0.5 MPa push force, the computed safe working load is roughly 2356 N, translating to a vertical lift capacity of about 200 kg with a 2:1 margin. This SKU lacks the S suffix for a magnet, so it cannot accept a magnetic switch.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×1000 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A Is Used
Decentralized Press Clamping
Clamps heavy parts directly at the press station. The integrated 4M310 valve switches the 100mm bore instantly without running long tubing back to a central manifold.
Large Package Diverter
Pushes heavy pallets on a sorting line. One AC220V coil signal drives the 1000mm stroke diverter, saving manifold space while delivering 3927 N of push force.
Vertical Lift Gate
Raises a loading bay gate. The built-in valve handles the 3/8 inch port flow locally, ideal for isolated actuators where a remote valve would require excessive plumbing.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A the Right Choice?
Size this 100mm bore against the neighboring 80mm option: the 100mm yields 3927 N push at 0.5 MPa versus 2513 N for the 80mm. Confirm the AC220V terminal entry coil matches your supply. The default action retracts the rod when energized, but you can reconfigure it to extend by repositioning the valve. Size force strictly within the 0.15-0.8 MPa valve range, never the 1.0 MPa cylinder body rating. The built-in valve routes air and is not a lock; the piston drifts on air loss, so add an external rod lock or pilot-operated check valve to hold a load. For the 1000mm stroke, use external guides to prevent rod bending and side-load damage.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000-10A FAQ
It pushes 3927 N and pulls 3681 N at 0.5 MPa. The built-in valve is a 4M310-10 (5/2 solenoid) with a 3/8 inch port, Cv 1.68, and runs up to 4 cycles per second. The coil is AC220V with terminal entry. You must size force within the 0.15-0.8 MPa valve operating window, not the 1.0 MPa cylinder body rating.
Yes. The default action retracts the rod when energized, but you can reposition the valve on the cap to make it extend instead. Because the valve only routes air, it cannot hold the load on air loss; install an external rod lock or pilot-operated check valve for load holding.
