Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10A
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X1000S-10A Valve-Integrated Cylinder Specifications
- Model: SAUF100X1000S-10A
- Type: ISO15552-compliant pneumatic cylinder with integrated 5/2-way solenoid valve
- Bore size: 100mm
- Stroke: 1000mm (adjustable cushioning)
- Operating pressure: 0.05-1.0 MPa
- Port size: G3/8 (NPT1/2 optional)
- Cushioning type: Adjustable pneumatic cushion at both ends
- Voltage options: DC24V (±10%) / AC220V (±10%)
- Ambient temperature: -20℃ to 80℃ (non-freezing)
- Weight: 12.8kg ±5% (excluding accessories)
- Dimensions: 1210mm(L) × 128mm(W) × 128mm(H) (full extension)
- Rod diameter: 25mm (chrome-plated steel)
- Seal material: Polyurethane (NBR optional)
- Protection rating: IP54 (standard), IP67 with optional kit
- Mounting type: Fixed foot (ISO 15552 MF1)
- Max piston speed: 0.1-1.5 m/s
- Flow capacity: 1500 NL/min (at 0.5 MPa)
High-force cylinder with integrated directional control valve designed for long-stroke heavy-duty applications. Features corrosion-resistant anodized aluminum construction and magnetic piston for position sensing compatibility. The 10A suffix indicates enhanced seal configuration for high-cycle applications (up to 1 million cycles at rated load). Requires 5-40μm filtered lubricated air (ISO 8573-1 class 4).
- Press machine ejection systems
- Automotive assembly line clamping devices
- Plastic injection molding machine core-pull mechanisms
- Steel mill conveyor gate controls
- Large-scale packaging equipment actuators
- Mounting surface flatness ≤0.1mm/m
- Allow 150mm clearance at rod end for maintenance
- Use flexible couplings for stroke >500mm
- Lubricate with ISO VG32 hydraulic oil if using non-lubricated air
Warning:
Always install locknuts on adjustment screws after cushion tuning.
Avoid lateral loads exceeding 200N. Support rod end when mounted vertically downward.
| Property | Property Value |
|---|---|
| sku | SAUF100X1000S-10A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
