Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X1000S-10B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X1000S-10B Valve-Integrated Cylinder Specifications
- Model: SAUF100X1000S-10B
- Type: Double-acting cylinder with integrated 5/2-way solenoid valve
- Bore size: 100mm
- Stroke: 1000mm
- Operating pressure: 0.1–0.9 MPa
- Valve operation: Single/double solenoid (specify when ordering)
- Voltage options: DC12V/24V, AC110V/220V (±10% tolerance)
- Port size: G1/2 (ISO standard)
- Cushioning: Adjustable pneumatic cushion at both ends
- Seal material: NBR + Polyurethane combination
- Temperature range: -20℃ to 80℃
- Protection rating: IP67 (valve section), IP40 (cylinder body)
- Weight: ~38.5kg (excluding mounting accessories)
- Dimensions: 1180mm(L) × 135mm(W) × 135mm(H) (full extension)
- Piston rod diameter: 25mm (chrome-plated steel)
- Max thrust: 706N @0.6MPa (extending)
- Response time: ≤100ms (valve switching)
High-force integrated cylinder-valve unit designed for heavy-duty linear motion applications. Features corrosion-resistant aluminum alloy barrel and centralized pneumatic control through built-in manifold. The compact valve mounting reduces piping complexity by 75% compared to separate components. Includes magnetic piston for position sensing compatibility.
- Injection molding machine ejector systems
- Automotive assembly line clamping devices
- Steel coil handling equipment
- Large-format CNC router tool changers
- Industrial press feeding mechanisms
Installation guidelines:
Mount using ISO 15552 standard brackets. Maintain 0.5-1mm alignment tolerance during installation.
Requires 5μm filtered lubricated air (ISO 8573-1:2010 Class 4). Perform lubrication checks every 2,000km of cumulative stroke movement.
Critical note:
When operating at maximum stroke length, reduce maximum pressure by 15% to prevent piston rod buckling.
Not recommended for vertical mounting without additional guide mechanisms.
| Property | Property Value |
|---|---|
| sku | SAUF100X1000S-10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
