Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A
The AirTAC Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A is a genuine double-acting profile-type cylinder with a Ø100mm bore, 100mm stroke and a built-in 4M310-10 5/2 solenoid valve — it switches itself from one coil signal, so no separate remote valve or extra plumbing is needed.
- BoreØ100 mm
- Stroke100 mm
- Built-in valve4M310-10
- Valve port3/8"
- CoilAC220V
- EntryTerminal
About the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A
The SAUF100X100S-10A is a double-acting profile cylinder with a built-in AirTAC 4M310 5/2 solenoid valve on the cap. One coil signal drives the actuator, eliminating remote plumbing and saving a manifold slot. The 100mm bore has a 1/2" air port, an M20x1.5 rod thread, and 29mm adjustable cushions.
Driven by an AC220V terminal-entry coil, the integrated 4M310-10 valve has a 3/8" port, Cv 1.68 flow, and cycles up to 4 times per second. The cylinder body rates to 1.0 MPa, but the assembled unit operates within the valve's 0.15-0.8 MPa window. At 0.5 MPa it pushes 3927 N; the safe working load is roughly 2356 N, allowing a 2:1 vertical lift of about 200 kg.
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A Technical Specifications
| Model | Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A |
|---|---|
| Series | SAUF profile cylinder with valve |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, self-valved |
| Cylinder port | 1/2" |
| Rod thread | M20×1.5 |
| PU tube | Ø10 × Ø6.5 |
| Built-in valve | 4M310-10 (5/2) |
|---|---|
| Valve flow | 30.0 mm² (Cv 1.68) |
| Max frequency | 4 cycle/sec |
| Coil voltage | AC220V · AC 3.5 VA |
| Electrical entry | Terminal · IP65 · B class |
| Response time | 0.05 s and below |
| Operating pressure | 0.15 – 0.8 MPa (valve limit) |
| Speed range | 30 – 800 mm/s |
The cylinder rates to 1.0 MPa but the built-in valve operates 0.15–0.8 MPa, so run the assembled SAUF at 0.15–0.8 MPa. Default: rod retracts when the coil is energised (reconfigurable to extend). Specs follow the official AirTAC SAUF datasheet. Port options: PT / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
Sized within the valve's 0.15–0.8 MPa range. Actual usable force is lower than theoretical due to friction and back-pressure.
Model Code: Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A
| SAUF | Profile cylinder with built-in 4M valve. |
|---|---|
| 100×100 | Bore × stroke in mm. |
| -10 | Valve port 3/8" → 4M310-10. |
| A | Coil voltage AC220V. |
| I / (blank) | Terminal electrical entry. |
SAUF does not hold its load without air — the valve routes air, it is not a lock. For a held load, add an external rod lock or a pilot-operated check valve.
Where the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A Is Used
Heavy Press Clamping
Provides localized high-force clamping on a machining line, switching directly from one AC220V signal without a central manifold.
Pallet Lift Stations
Handles vertical lifting in decentralized packaging zones, using the built-in 4M310 valve to save installation tubing across the cell.
Automated Forming Dies
Delivers 3927 N push force at 0.5 MPa directly inside large dies, simplifying control logic by integrating the 5/2 valve on the cap.
Is the Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A the Right Choice?
Size by force: this 100mm bore pushes 3927 N at 0.5 MPa, whereas the 80mm neighbor pushes 2513 N. Confirm your coil is AC220V with terminal entry. The unit defaults to retract-when-energised but can be reconfigured to extend by repositioning the valve. Always size force within the 0.15-0.8 MPa valve limit. The valve routes air and is not a lock; add an external rod lock or pilot-operated check valve to hold a load. For strokes over 300mm, use side-load guides.
Quick checklist
- ✓ Force at 0.15–0.8 MPa
- ✓ Coil voltage matches panel
- ✓ Terminal vs grommet entry
- ✓ Retract- or extend-when-energised
- ✓ Load-holding → external rod lock
Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X100S-10A FAQ
It pushes 3927 N and pulls 3681 N at 0.5 MPa. The built-in valve is a 4M310-10 with Cv 1.68 and a 3/8" port. The coil is AC220V. Although the cylinder body rates to 1.0 MPa, the assembled unit must operate within the valve's 0.15-0.8 MPa window.
Yes, the default action is retract-when-energised, but you can reposition the valve to extend-when-energised. The valve only routes air; it is not a load lock. For load holding on air loss, install an external rod lock or pilot-operated check valve.
