Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X125-10B
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X125-10B Valve-Integrated Cylinder Specifications
- Model: SAUF100X125-10B
- Type: Compact cylinder with integrated 5/2-way solenoid valve
- Bore size: Ø100mm
- Stroke: 125mm (adjustable cushioning)
- Operating pressure: 0.1–0.9 MPa
- Port size: G3/8 (NPT1/2 optional)
- Voltage options: DC24V (±10%), AC110V/220V (±15% 50/60Hz)
- Valve type: Monostable with spring return
- Seal material: NBR (Nitrile) standard, optional FKM
- Temperature range: -20℃ to +80℃
- Weight: 6.8kg (including valve assembly)
- Dimensions: 258mm(L) × 128mm(W) × 128mm(H)
- Mounting type: Double-ended stud (ISO 15552 standard)
- Cushioning: Adjustable pneumatic cushion
- Sensor compatibility: Built-in magnet for proximity sensors
- Protection rating: IP67 (cylinder), IP65 (valve section)
Space-saving combination cylinder with integrated directional control valve, designed for high-force applications requiring centralized pneumatic control. Features anti-rotation rod design and corrosion-resistant aluminum alloy construction. The modular design allows optional mounting of magnetic switches (sensors sold separately).
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- Heavy-duty material handling systems
- Paper processing equipment actuators
- Automotive fixture positioning devices
Installation guidelines:
Ensure clean dry air supply (40μm filtration recommended).
Lubricate with ISO VG32 turbine oil if using non-lubricated air.
Avoid side load forces exceeding 30N·m. Allow 50mm clearance
around valve section for heat dissipation and maintenance access.
| Property | Property Value |
|---|---|
| sku | SAUF100X125-10B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | DC24V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
