Airtac SAUF Series Valve-Mounted Air Cylinder SAUF100X125S-10A
$192.85
Regular price
$200.35
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUF100X125S-10A
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Engineered as a derivative series integrating standard cylinders with valves, compatible with 4M210 (for 32mm, 40mm, 50mm bores) and 4M310 valves (for 63mm, 80mm, 100mm bores).
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
Installation guidelines:
Mount using M8x1.25 mounting bolts (max torque 12N·m). Maintain 20mm clearance
around valve section for heat dissipation. Use ISO VG32 hydraulic oil for
lubrication (drip feed 1 drop/5 cycles). Avoid side-load exceeding 50N.
2、Enables direct one-to-one pneumatic control without external valve installation.
3、Optimizes spatial efficiency and installation time, ideal for decentralized configurations in large-scale systems.
4、Supports multiple standardized mounting accessories for simplified integration.
Category: Valve-Equipped Cylinders | Brand: AirTAC | Series: SAUF
AirTAC SAUF100X125S-10A Valve-Integrated Cylinder Specifications
- Full model: SAUF100X125S-10A
- Type: Compact valve-integrated cylinder (double-acting)
- Bore size: Ø100mm
- Stroke: 125mm
- Operating pressure: 0.05–1.0 MPa
- Port thread: PT1/4 (G1/4 optional)
- Voltage variants: DC24V (±10%) / AC110V (50/60Hz) / AC220V (50/60Hz)
- Max thrust: 785N @0.7MPa
- Ambient temperature: -10℃ to 70℃ (no freeze)
- Weight: 3.8kg (including valve)
- Dimensions: 300mm(L) × 100mm(W) × 160mm(H)
- Cushioning: Adjustable pneumatic cushion
- Seal material: NBR (nitrile rubber)
- Protection class: IP67 (dust/water resistant)
- Response time: ≤50ms (valve switching)
Integrated cylinder-valve unit combining compact design with high power density. Features built-in speed controller and auto-switching lubrication structure. The aluminum alloy body with hard anodizing resists industrial corrosion. Designed for ISO 15552 mounting compatibility.
Industrial Applications:
- High-cycle press machines (stamping/ejection)
- Automated material handling systems
- Plastic injection molding clamp units
- Automotive welding fixture positioning
- Food processing conveyor gate control
Installation guidelines:
Mount using M8x1.25 mounting bolts (max torque 12N·m). Maintain 20mm clearance
around valve section for heat dissipation. Use ISO VG32 hydraulic oil for
lubrication (drip feed 1 drop/5 cycles). Avoid side-load exceeding 50N.
| Property | Property Value |
|---|---|
| sku | SAUF100X125S-10A |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Standard Voltage | AC220V |
| Solenoid Valve Model | 4M Series, 31mm Bore, 80mm Stroke, M9W Sensor |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 125mm |
