Airtac SC80 Standard Cylinder SC80X1000SLB
The AirTAC Airtac SC80 Standard Cylinder SC80X1000SLB is a genuine double-acting standard air cylinder with a Ø80mm bore and 1000mm stroke, PT3/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ80 mm
- Stroke1000 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 28 mm
About the Airtac SC80 Standard Cylinder SC80X1000SLB
The SC80X1000SLB is a double-acting tie-rod cylinder delivering a push force of 2513 N at 0.5 MPa and up to 4523 N at 0.9 MPa. With an 80 mm bore and a 1000 mm stroke, this model features a 25 mm diameter piston rod and PT3/8 ports, making it a robust choice for long linear movements.
This configuration includes a built-in magnet (-S) for mounting CMSG/DMSG/EMSG sensors directly on the barrel, enabling precise end-of-stroke detection. The LB foot mounting (F-SC80LB) provides stable surface fixation, while the 28 mm adjustable air cushion at each end decelerates the piston smoothly to reduce impact at the end of its travel.
Airtac SC80 Standard Cylinder SC80X1000SLB Technical Specifications
| Model | Airtac SC80 Standard Cylinder SC80X1000SLB |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø80 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 28 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (approx.) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC80 Standard Cylinder SC80X1000SLB
| SC | Standard tie-rod cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC80 Standard Cylinder SC80X1000SLB Is Used
Packaging Line Diverter
Operates a 1000 mm stroke diverter gate on a packaging line, using the built-in magnet for position feedback to the PLC.
Laminating Press Feed
Pushes heavy wooden panels through a 1-meter wide laminating press, leveraging the 2513 N force at standard shop air pressure.
Pallet Transfer System
Drives a long-stroke pallet transfer mechanism, with the LB foot mounts bolted securely to the conveyor frame for rigid alignment.
Is the Airtac SC80 Standard Cylinder SC80X1000SLB the Right Cylinder?
Select the SC80 bore when your application requires between 2513 N and 4523 N of force. For lighter loads, stepping down to an SC63 bore provides 1559 N at 0.5 MPa, while stepping up to an SC100 bore offers 3927 N at the same pressure. For this 1000 mm stroke, ensure the load is guided externally to prevent side-load bending on the 25 mm rod.
For a direct replacement, match five key points: an 80 mm bore, 1000 mm stroke, PT3/8 port thread, LB foot mounting, and the -S magnet for sensor compatibility. Always verify the tie-rod construction, as this is not an ISO 15552 profile cylinder.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC80 Standard Cylinder SC80X1000SLB FAQ
At 0.5 MPa, it provides 2513 N pushing force and 2268 N pulling force. At the maximum operating pressure of 0.9 MPa, the pushing force increases to 4523 N.
You must match the 80 mm bore, 1000 mm stroke, PT3/8 ports, LB foot mounting, and the -S magnet for sensors. The SC is a tie-rod cylinder and is dimensionally shorter than a standard ISO 15552 cylinder, so it is not a drop-in replacement for those profiles.
