Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X15-20SB
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X15-20SB Adjustable Slim Cylinder Specifications
- Model Series: SDAJ12~25 (12mm to 25mm bore sizes)
- Specific Model: SDAJ12X15-20SB
- Bore Size: 12mm
- Stroke Range: Adjustable 15-20mm (±1mm tolerance)
- Mounting Type: Compact flange/clevis hybrid design
- Port Size: 1/8" NPT (G1/8 optional)
- Operating Pressure: 0.15-0.8 MPa (21.7-116 PSI)
- Cushioning: Adjustable pneumatic cushion
- Temperature Range: -20℃ to 80℃ (NBR seals)
- Seal Material: NBR standard (PU available for high-speed apps)
- Weight: 0.25kg (unlubricated)
- Dimensions (L×W×H):
- Basic length: 70mm (at 20mm stroke)
- Body width: 25mm
- Height with mount: 34mm
- Rod end thread: M5×0.8
Ultra-low profile cylinder with stroke adjustment mechanism (rotation-lock collar) for precision positioning. Features double-acting operation, corrosion-resistant aluminum alloy body, and integrated mounting flexibility. The "SB" suffix indicates special brass piston nut for enhanced durability.
- PCB handling robots requiring ≤35mm height clearance
- Medical device clamp actuators
- Semiconductor wafer positioning stages
- Packaging machine micro-feeding systems
- 3C product assembly automation
Usage Tip:
For stroke adjustment, loosen lock nut and rotate cylinder barrel - each full rotation changes stroke by 0.5mm. Lubricate with ISO VG32 turbine oil when used in high-cycle (>5Hz) applications.
| Property | Property Value |
|---|---|
| sku | SDAJ12X15-20SB |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <15mm> |
