Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-10SB
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X20-10SB Adjustable Slim Cylinder Specifications
- Series: SDAJ12~25 (Ultra-slim design series)
- Bore size: 12mm
- Stroke: 20mm (±1mm adjustability)
- Mounting type: Compact flange mounting (CAC pattern)
- Port size: PT1/8 (G1/8 optional)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable air cushion (dual side)
- Position detection: Magnet compatible (T-slot for sensor mounting)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body (anodized), CRMo steel piston rod
- Seal material: NBR (Nitrile rubber) standard, optional FKM
- Weight: 0.24kg (excluding accessories)
- Dimensions:
- Length: 70mm (min. folded length: 52mm)
- Width: 34mm (flange mounting surface)
- Height: 34mm (including cushion screws)
Industry's thinnest profile cylinder (only 12mm wall thickness) with precision stroke adjustment via locknut mechanism. Features integrated mounting grooves for proximity sensors and corrosion-resistant hard anodized surface. Designed for applications requiring space optimization without compromising 1,500km+ service life. Lubrication-free operation with wiper seal protection.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer systems
- Automated optical inspection (AOI) equipment
- Medical device assembly lines
Installation note:
Maximum lateral load 5N·m. Use M3x0.5 mounting screws with 0.4-0.6N·m torque.
For vertical mounting, install cushion screws upward. Maintain 0.5mm clearance
between sensor and magnetic piston.
| Property | Property Value |
|---|---|
| sku | SDAJ12X20-10SB |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
