Airtac SDAJ12~25 Adjustable Ultra-Thin Cylinder SDAJ12X20-20SB
1. Manufactured in compliance with enterprise standards;
2. Features riveted integration between cylinder barrel/rear cover and piston/piston rod for compact reliability;
3. Barrel bore undergoes precision roller burnishing followed by hard anodizing for superior wear resistance and extended service life;
4. Patented asymmetric bidirectional piston sealing design with integrated lubrication reservoirs ensures space efficiency;
5. Optimized footprint minimizes installation spatial requirements;
6. Pre-machined sensor mounting grooves around barrel periphery enable tool-free sensor installation;
7. Multiple configurations available to accommodate specific application requirements.
Category: Slim Cylinders | Brand: AIRTAC | Series: SDAJ12~25
AirTAC SDAJ12X20-20SB Ultra-Slim Adjustable Cylinder Specifications
- Series: SDAJ12~25 Compact Cylinder Series
- Full model: SDAJ12X20-20SB
- Bore size: 12mm (SDAJ12)
- Stroke: 20mm (adjustable ±5° end rotation)
- Port size: M5x0.8 (dual auto switch ports)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffer
- Temperature range: -10℃ to 70℃
- Seal material: NBR (nitrile) with wear-resistant ring
- Mounting type: Basic non-rotating flange (optional side mount brackets available)
- Weight: 0.18kg (excluding accessories)
- Dimensions: 38mm(W) × 20mm(H) × 63.5mm(L)
- Rod thread: M5×0.8 external thread
- Repeat accuracy: ±0.5mm
- Max speed: 500mm/s
Industry's thinnest 12mm bore cylinder (20mm height profile) with integrated auto switches. Features dual-position sensing via magnetic piston and steel-reinforced aluminum alloy body. The 20SB variant includes two 3-wire NPN/PNP compatible inductive sensors with LED status indicators. Adjustable cushioning prevents piston impact at stroke ends.
- PCB board clamping in SMT assembly lines
- Precision lens positioning in optical equipment
- Miniature part ejection in micro-molding machines
- Compact door actuators in cleanroom environments
- Robotic end-effector tool changers
Installation tip:
Maintain 0.5mm clearance between cylinder body and adjacent components for heat dissipation.
Use locknuts (not included) on rod end threads for force adjustment. Lubricate through air supply (ISO VG32 recommended).
| Property | Property Value |
|---|---|
| sku | SDAJ12X20-20SB |
| Adjustable Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Stroke | <20mm> |
