The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X10-10B is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.
The AirTAC SDAJ32X10-10B is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. Turning the R (M10x1.25) screw lets you dial the extend position on-site from 0 to 10 mm without changing parts.
This thin riveted-body design saves axial mounting depth where round-body or profile alternatives will not fit. It features a fixed NBR bumper at each end to decelerate the stroke, operating effectively within a 30-500 mm/s speed range. This specific SKU includes a male M10x1.25 piston rod thread and lacks a piston magnet, meaning it cannot support reed or electronic switches without upgrading to the -S variant.
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X10-10B |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 10 mm |
| Adjustable range | 0 – 10 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×10 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial in the exact 0-10 mm clamping reach on machining fixtures using the M10x1.25 male rod, ensuring 402.1 N of secure holding force without over-travel.
Fit the short riveted body into tight assembly machinery footprints to seat delicate parts, adjusting the extend stop on-site to accommodate material thickness variations.
Rapidly reconfigure end-stops during production line changeovers, turning the external R screw to shift the extend endpoint instead of swapping out entire actuators.
When sizing this 32 mm bore, evaluate your force requirements carefully against its neighbours.
Choose this model when your fixture requires on-site stroke tuning between 0 and 10 mm via the male M10x1.25 rod. Confirm your setup needs the PT1/8 air port and accepts a non-sensing piston. Note that a plain cylinder does not hold its load on air loss or when the valve is centered; the piston drifts and the fixed bumper only decelerates near the end. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.
Quick checklist
The theoretical maximum push force is 82 kgf at 1.0 MPa.
The R (M10x1.25) adjuster screw mechanically shortens the extend stroke by up to 10 mm, yielding a usable extend range of 0-10 mm. This SKU features a male M10x1.25 piston rod thread and lacks a piston magnet, so it cannot accept reed or electronic switches.
