Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100 is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 0 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range0–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100
The AirTAC SDAJ32X100-100 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. By turning the R (M10x1.25) screw, you can dial the extend position anywhere between 0 and 100 mm directly on the machine, eliminating the need for shims or part swaps during changeovers. Retract remains a full stroke.
The short riveted body saves axial mounting depth where round-body or profile cylinders will not fit. End shock is managed solely by a fixed NBR bumper, which decelerates the stroke end but is not an adjustable air cushion. Note this SKU lacks a piston magnet and cannot accept a magnetic switch.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100 Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 0 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 100 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -100 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100 Is Used
Trial Positioning Jigs
Dial in the exact extend stop from 0 to 100 mm during prototype runs.
Multi-Format Changeovers
Adapt packaging lines to different carton sizes instantly. The external M10x1.25 screw allows rapid repositioning without disassembling the cylinder.
Short-Depth Assembly Stations
Fit the compact riveted body into tight machine frames. The fixed NBR bumper absorbs end shock reliably in high-cycle automated insertion tasks.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100 the Right Cylinder?
Choose this specific unit if your fixture requires frequent on-site stroke tuning across the full 0-100 mm window.
Confirm your parameters: 32 mm bore, 100 mm maximum stroke, 100 mm adjustment window, and a PT1/8 air port. This configuration has a female M6x1.0 rod-end thread and no magnet (no -S code). A plain cylinder does not hold its load on air loss or when the valve is centred—the piston drifts and the fixed bumper only decelerates near the end. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 0–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-100 FAQ
The theoretical maximum push is 82 kgf at 1.0 MPa.
Turning the R (M10x1.25) screw shortens the extend stop by up to 100 mm, giving a usable extend range of 0-100 mm; the retract stroke remains full. This specific SKU has no magnet and cannot take a switch. The -S variant adds a magnet for reed or electronic switches.
