Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-30S
2、Features riveted connection between cylinder body/rear cap and piston/piston rod for enhanced structural integrity;
3、Precision roller burnishing followed by hard anodizing treatment on inner bore surface ensures superior wear resistance and durability;
4、Unique custom bi-directional sealing profile with integrated oil reservoir optimizes compactness and lubrication retention;
5、Space-saving design minimizes installation footprint while maintaining performance;
6、Integrated sensor grooves along cylinder periphery facilitate effortless sensor mounting;
7、Available in multiple mounting configurations for flexible system integration.
Category: Slim Cylinders , Brand: AirTAC , Series: SDAJ32~40 Adjustable Ultra-Compact Cylinders
AirTAC SDAJ32X100-30S Adjustable Ultra-Thin Cylinder Specifications
- Model: SDAJ32X100-30S
- Series: SDAJ32~40 (32mm/40mm bore sizes)
- Type: Adjustable stroke ultra-compact cylinder
- Bore size: 32mm
- Stroke: 100mm (adjustable via built-in stroke adjustment mechanism)
- Mounting style: Standard ISO 15552 front flange with accessory compatibility
- Buffer type: Adjustable pneumatic cushioning (both ends)
- Operating pressure: 0.1~0.9 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Nitrile) / Optional Polyurethane seals
- Port size: PT1/8 (G1/8 optional)
- Piston speed: 50~800 mm/s
- Weight: 1.2 kg (excluding accessories)
- Dimensions (L×W×H): 180mm × 50mm × 50mm (at full extension)
- Rod thread: M10×1.25 (ISO standard)
- Protection rating: IP54 (standard seals)
- Lubrication: Pre-lubricated (maintenance-free for 2000km operation)
Ultra-slim profile cylinder (30% thinner than standard models) with precision stroke adjustment capability. Features double-acting operation with magnetic piston for position sensing compatibility. Anodized aluminum construction with chrome-plated piston rod ensures corrosion resistance. Designed for applications requiring space optimization without compromising force output (max thrust: 206N at 0.6MPa).
- High-density automation equipment with limited space
- Precision clamping in semiconductor manufacturing
- Z-axis positioning in CNC tool changers
- Packaging machine ejector systems
- Medical device actuation mechanisms
- Robotic end-effector tooling
Installation note:
Ensure proper alignment of guide rails when used in vertical orientation.
Recommended mounting torque: 12-15 N·m for flange screws. Lubricate rod
with ISO VG32 hydraulic oil if operated in high-cycle applications (>5 cycles/sec).
- Mounting brackets: MA-32 series
- Rod end types: CEI/CEF/CEM configurations
- Position sensors: SNS-L series magnetic switches
- Speed controllers: ASC-04 adjustable flow valves
| Property | Property Value |
|---|---|
| sku | SDAJ32X100-30S |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
