Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-40SB
$72.55
Regular price
$80.05
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ32X100-40SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Complies with corporate technical standards;
2、Features riveted connection between cylinder body/rear cap and piston/piston rod for enhanced structural integrity;
3、Precision roller burnishing followed by hard anodizing treatment on inner bore surface ensures superior wear resistance and durability;
4、Unique custom bi-directional sealing profile with integrated oil reservoir optimizes compactness and lubrication retention;
5、Space-saving design minimizes installation footprint while maintaining performance;
6、Integrated sensor grooves along cylinder periphery facilitate effortless sensor mounting;
7、Available in multiple mounting configurations for flexible system integration.
Category: Slim Cylinders , Brand: AirTAC , Series: SDAJ32~40 Adjustable Ultra-Compact Cylinders
Installation tips:
Maintain ≤0.5mm alignment tolerance during mounting. Use flexible couplings
when connecting to guided mechanisms. For vertical mounting, install rod-down
orientation to prevent dust accumulation. Lubricate every 500km stroke in high-cycle applications.
2、Features riveted connection between cylinder body/rear cap and piston/piston rod for enhanced structural integrity;
3、Precision roller burnishing followed by hard anodizing treatment on inner bore surface ensures superior wear resistance and durability;
4、Unique custom bi-directional sealing profile with integrated oil reservoir optimizes compactness and lubrication retention;
5、Space-saving design minimizes installation footprint while maintaining performance;
6、Integrated sensor grooves along cylinder periphery facilitate effortless sensor mounting;
7、Available in multiple mounting configurations for flexible system integration.
Category: Slim Cylinders , Brand: AirTAC , Series: SDAJ32~40 Adjustable Ultra-Compact Cylinders
AirTAC SDAJ32X100-40SB Adjustable Slim Cylinder Specifications
- Model: SDAJ32X100-40SB
- Bore size: 32mm (SDAJ32 series)
- Stroke: 100mm (adjustable ±2mm via stopper)
- Type: Double-acting ultra-slim cylinder
- Mounting style: Basic (optional foot/axial/flange mounts)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable rubber bumper
- Port size: M5x0.8 (G1/8 optional)
- Piston rod thread: M10x1.25
- Temperature range: -20℃ to 80℃
- Material:
- Tube: Anodized aluminum alloy
- Piston rod: Chrome-plated steel
- End caps: Die-cast aluminum
- Weight: 680g (excluding accessories)
- Dimensions:
- Total length: 173mm (at mid-stroke)
- Body width: 40mm
- Height: 40mm (excluding rod)
- Seal material: NBR/PU
- Protection rating: IP54 (standard), IP67 (optional)
- Lubrication: Pre-lubricated (use ISO VG32 oil if maintained)
Ultra-compact profile (only 40mm height) with 32mm bore delivers 142N thrust at 0.5MPa. Features dual anti-rotation guides and non-rotating piston rod for precision positioning. The anodized body resists chemical corrosion in harsh environments.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Clamping mechanisms in CNC tool changers
- Valve actuation in food packaging lines
- Z-axis positioning in 3D printers
- Medical device assembly systems
Installation tips:
Maintain ≤0.5mm alignment tolerance during mounting. Use flexible couplings
when connecting to guided mechanisms. For vertical mounting, install rod-down
orientation to prevent dust accumulation. Lubricate every 500km stroke in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SDAJ32X100-40SB |
| Adjustable Stroke | <40mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
