Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75
The AirTAC SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75 is a genuine double-acting COMPACT cylinder (Ø32mm bore) whose extend end-position is set by an external M10×1.25 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.
- BoreØ32 mm
- Max stroke100 mm
- Adjustable range25–100 mm
- Adjuster threadM10×1.25
- Port sizePT1/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75
The AirTAC SDAJ32X100-75 is a compact double-acting double-rod cylinder featuring an external adjustable extend stop. An M10x1.25 adjuster screw lets you dial the outward stroke anywhere between 25 and 100 mm directly on the machine, eliminating the need for shims or part swaps.
Its short riveted body saves valuable axial mounting depth where larger profile cylinders cannot fit. End-of-travel deceleration is handled by a fixed NBR bumper, which absorbs shock but is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot support reed or electronic switches without upgrading to the -S variant.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75 Technical Specifications
| Model | Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75 |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Max stroke | 100 mm |
| Adjustable range | 25 – 100 mm |
| Adjuster thread (R) | M10×1.25 |
| Port size | PT1/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M6×1.0 F / M10×1.25 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 346 N | 346 N |
| 0.7 MPa | 484 N | — |
| Max (@1.0 MPa) | 70 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -75 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75 Is Used
Variable-Length Diverter
Adjust the extend stop on-site to sort different package sizes without swapping hardware, using the compact riveted body to fit within tight transfer station frames.
Is the Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75 the Right Cylinder?
When sizing this 32 mm bore actuator, evaluate your force requirements both ways. Choose this 100 mm maximum stroke unit if your fixture requires extensive on-site stroke tuning across its 75 mm adjustment window.
Confirm your requirements for bore, stroke, window, PT1/8 port, female M6x1.0 rod-end thread, and the absence of a magnet. Crucially, a standard cylinder does not hold a load when air pressure drops or the valve is centred; the piston drifts. For secure load holding without live pressure, integrate an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 25–100 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M10×1.25 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ32~40 Adjustable Super Slim Cylinder SDAJ32X100-75 FAQ
It operates at 30-500 mm/s and accepts pressures from 0.15 to 1.0 MPa.
Turning the external R (M10x1.25) screw shortens the extend stroke by up to 75 mm, allowing the outward position to be set anywhere from 25 to 100 mm. This screw acts only as a mechanical stop and does not lock the piston; for load holding on air loss, you need an external rod lock or pilot-operated check valve.
