Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-10B
$88.37
Regular price
$95.87
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ50X100-10B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
Installation tip:
Use precision alignment tools during mounting to prevent side load.
For vertical installations, add 20% extra stroke margin to account for
gravitational overtravel. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃.
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-10B Adjustable Ultra-Thin Cylinder Specifications
- Series: SDAJ50~63 (Compact Series)
- Model Code Breakdown: SDAJ50X100-10B
- 50: Bore size (50mm)
- 100: Stroke length (100mm)
- 10B: Mounting type (Standard front flange with auto switch slot)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Piston speed: 50–1000 mm/s
- Port size: M5×0.8 (Standard) / NPT1/8 (Optional)
- Rod end thread: M10×1.25
- Body material: Aluminum alloy (anodized)
- Seal material: NBR + PU combination
- Weight: 1.25 kg (with rod) ±3%
- Dimensions:
- Length: 178mm (retracted) / 278mm (extended)
- Width: 64mm (max body width)
- Height: 64mm (including mounting flange)
- ISO Standard: 6432-compliant
- Accessory compatibility: Compatible with SNS-L series magnetic sensors
Ultra-slim profile cylinder (height reduced 30% vs standard models) with stroke adjustment mechanism. Features dual anti-rotation design and multiple mounting options. The through-rod design allows external position feedback. Optimized for high-frequency cycling (up to 5Hz continuous operation).
Typical Applications:
- PCB handling robots in electronics manufacturing
- Cartesian coordinate positioning systems
- Medical device actuation mechanisms
- Semiconductor wafer clamping devices
- Automated conveyor diverters
Installation tip:
Use precision alignment tools during mounting to prevent side load.
For vertical installations, add 20% extra stroke margin to account for
gravitational overtravel. Lubricate with ISO VG32 hydraulic oil
if operating below -10℃.
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-10B |
| Adjustable Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
