Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-30SB
$101.19
Regular price
$108.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SDAJ50X100-30SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with enterprise standards;
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
Installation notes:
2. Features riveted structure integrating cylinder body with rear end cap, piston with piston rod for reinforced compactness and reliability;
3. Cylinder bore undergoes precision roller burnishing followed by hard anodized treatment, delivering exceptional wear resistance and long-term durability;
4. Custom-profile bidirectional piston seal configuration with integrated oil reservoir ensures space-efficient sealing performance;
5. Ultra-slim profile maximizes space utilization in confined installations;
6. Perimeter sensor grooves enable tool-free magnetic switch mounting;
7. Multiple configuration options across standardized specifications.
Category: Compact Cylinders | Brand: AirTAC | Series: SDAJ50~63
AirTAC SDAJ50X100-30SB Adjustable Slim Cylinder Specifications
- Series: SDAJ50~63 (50mm/63mm bore sizes)
- Full model: SDAJ50X100-30SB
- Bore size: 50mm
- Stroke: 100mm (adjustable via external stopper)
- Operating pressure: 0.05~0.9 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Cushioning type: Rubber buffer + adjustable stroke mechanism
- Piston speed: 50~800 mm/s
- Seal material: NBR (standard) / FKM (optional)
- Mounting type: Basic type (no built-in mounting brackets)
- Weight: 1.35 kg (excluding accessories)
- Dimensions:
- Length: 179mm (fully extended)
- Width: 64mm (body width)
- Height: 50mm (cylinder outer diameter)
- Protection rating: IP54 (standard sealing)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil)
Ultra-compact profile cylinder (height ≤50mm) with external stroke adjustment capability, featuring a dual-guide rod structure for enhanced lateral load capacity. The 30SB variant includes a magnetic piston for position sensing compatibility. Designed for high-frequency operations (≤3Hz) with reduced installation space requirements.
Typical Applications:
- PCB handling robots in electronics assembly
- Precision clamping in CNC tool changers
- Material sorting gates in packaging lines
- Actuation in cleanroom automation (medical devices)
- 3C product testing equipment positioning
Installation notes:
- Maintain 0.5mm minimum clearance between rod ends and adjacent components
- For vertical mounting, use auxiliary support brackets (optional AS-M12 kit)
- Maximum side load: 15N at full extension (lubrication critical)
Maintenance cycle:
- Relubricate every 500km of cumulative travel
- Inspect rod seals every 1 million cycles in dusty environments
- Replace cushion rings after 2 million full-stroke operations
| Property | Property Value |
|---|---|
| sku | SDAJ50X100-30SB |
| Adjustable Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/4 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
