The AirTAC SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75S is a genuine double-acting COMPACT cylinder (Ø50mm bore) whose extend end-position is set by an external M16×1.5 adjustment screw. You can dial the stroke anywhere from 25 to 100 mm on the machine — no shims, no part change.
The AirTAC SDAJ50X100-75S is a compact double-acting double-rod cylinder engineered for on-site stroke tuning.
Its short riveted body saves axial mounting depth where round-body or profile cylinders will not fit. The unit includes a built-in piston magnet for AirTAC reed or electronic switches, while a fixed NBR bumper decelerates the stroke end without acting as a mid-stroke lock.
| Model | Airtac SDAJ50~63 Adjustable Ultra-Thin Cylinder SDAJ50X100-75S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø50 mm |
| Max stroke | 100 mm |
| Adjustable range | 25 – 100 mm |
| Adjuster thread (R) | M16×1.5 |
| Port size | PT1/4 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M10×1.5 F / M18×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 75 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 825 N | 825 N |
| 0.7 MPa | 1155 N | — |
| Max (@1.0 MPa) | 168 kgf | |
SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 50 | Bore size in mm. |
| ×100 | Maximum stroke length in mm. |
| -75 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Dial the extend stop from 25 to 100 mm via the M16x1.5 screw during machine setup, accommodating different fixture heights without swapping cylinders.
Set precise upper travel limits for 50 kg vertical lifts using the mechanical stop, ensuring safe positioning while using an external check valve for load holding.
Choose this model for changeover-heavy lines needing precise extend positioning. Confirm your 50 mm bore, 100 mm maximum stroke, 75 mm window, PT1/4 port, female M10x1.5 rod thread, and the -S magnet. Remember that a plain cylinder drifts on air loss; for load holding without live pressure, install an external rod lock or pilot-operated check valve.
AirtacDistr lists every SDAJ50 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj50-adjustable-cylinder
Quick checklist
At 0.7 MPa, push is 1374.4 N. The theoretical maximum push is 200 kgf at 1.0 MPa.
The external R (M16x1.5) screw mechanically shortens the extend stroke by up to 75 mm, allowing on-machine tuning between 25 and 100 mm. The included -S magnet enables position sensing with AirTAC reed or electronic switches.
