AirTAC SDAJ Series · Adjustable-Stroke Compact Cylinder

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10

The AirTAC SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10 is a genuine double-acting COMPACT cylinder (Ø100mm bore) whose extend end-position is set by an external M27×2.0 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.

  • BoreØ100 mm
  • Max stroke10 mm
  • Adjustable range0–10 mm
  • Adjuster threadM27×2.0
  • Port sizePT3/8
  • CushionFixed NBR bumper (both ends)
$139.80 $147.30Save 5% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SDAJ100 stroke, mounting and version on one page All SDAJ100 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10

The AirTAC SDAJ100X10-10 is a compact double-acting double-rod cylinder built for high-force tasks in tight axial footprints. Its external R (M27x2.0) adjuster screw lets you dial the extend stop down from 10 mm to 0 mm directly on the machine, eliminating the need for shims or part swaps during commissioning.

This 100 mm bore model features a 32 mm rod and a PT3/8 port to handle substantial air volume. End-of-stroke energy is managed by a fixed NBR bumper that decelerates the piston, which is not an adjustable air cushion. Note that this specific SKU lacks a piston magnet, so it cannot support reed or electronic sensing without upgrading to the -S variant.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10 Technical Specifications

ModelAirtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10
SeriesSDAJ compact adjustable-stroke cylinder
Bore sizeØ100 mm
Max stroke10 mm
Adjustable range0 – 10 mm
Adjuster thread (R)M27×2.0
Port sizePT3/8
Acting typeDouble acting
Rod end threadM18×1.5 F / M26×1.5 male (B)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionFixed NBR bumper (both ends)

The adjustment screw shortens the extend stroke by up to 10 mm. SDAJ is a double-rod cylinder. Specifications follow the official AirTAC SDAJ datasheet.

Theoretical Output Force (Ø100mm)

PressurePush forcePull force
0.5 MPa3525 N3525 N
0.7 MPa4935 N—
Max (@1.0 MPa)719 kgf

SDAJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative), lower than a single-rod SDA push of the same bore. Actual usable force is lower than theoretical due to friction.

Model Code: Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10

SDAJCompact double-acting cylinder with adjustable stroke.
100Bore size in mm.
×10Maximum stroke length in mm.
-10Adjustable window (10/20/30/40/50/75/100 mm).
S / BS = magnet; B = male-thread rod (both optional).

Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).

Where the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10 Is Used

sync_alt

Changeover Positioning

Ideal for production lines with frequent format changes, allowing operators to reposition the extend endpoint mechanically without swapping cylinder hardware.

Is the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10 the Right Cylinder?

If your application requires less force, sizing down to the SDAJ80 offers 2513.3 N at 0.5 MPa, representing the nearest lower boundary. Since this is the largest standard compact bore, there is no larger SDAJ option; for even higher loads, you would need to explore non-compact alternatives.

This cylinder excels in setups requiring on-site stroke tuning between 0 and 10 mm. Confirm your requirements for the PT3/8 port, female M18x1.5 rod thread, and the absence of a magnet. Remember that a plain SDAJ does not hold position if air pressure drops or the valve is centered; the fixed bumper only decelerates near the end of travel. For secure load holding without live pressure, you must integrate an external rod lock or a pilot-operated check valve.

AirtacDistr lists every SDAJ100 order code with its price on one page at https://airtacdistr.com/products/airtac-sdaj100-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Target position within 0–10 mm
  • ✓ Force at your working pressure
  • ✓ Access to reach the R adjuster
  • ✓ Magnet (S) for sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Lock the M27×2.0 adjuster after setting the stroke.
  • check Avoid side load on the piston rod.
  • check Front/rear covers are riveted — do not dismantle.
  • check Installation by qualified personnel per AirTAC docs.

Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10 FAQ

Turning the M27x2.0 adjuster screw shortens the extend stroke by up to 10 mm, giving a usable extend range of 0 to 10 mm. The retract stroke remains full, and the screw acts purely as a mechanical stop without altering the output force.
