Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B
The AirTAC Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B is a genuine double-acting COMPACT cylinder (Ø100mm bore) whose extend end-position is set by an external M27×2.0 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.
- BoreØ100 mm
- Max stroke10 mm
- Adjustable range0–10 mm
- Adjuster threadM27×2.0
- Port sizePT3/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B
The AirTAC SDAJ100X10-10B is a compact double-acting single-rod cylinder built for tight axial spaces, delivering a massive 3927 N push at 0.5 MPa. Its short riveted body saves mounting depth where larger profile or round-body units fail to fit. An external R (M27x2.0) adjuster screw lets you dial the extend stop from 0 to 10 mm directly on the machine without swapping parts.
This variant features a male M26x1.5 piston rod thread and a PT3/8 air port. Because the adjuster sets the mechanical stop rather than altering the piston area, output force remains identical to a standard SDA of this bore. A fixed NBR bumper decelerates the stroke end, but note this unit lacks a piston magnet, so it cannot support reed or electronic switches.
Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B Technical Specifications
| Model | Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø100 mm |
| Max stroke | 10 mm |
| Adjustable range | 0 – 10 mm |
| Adjuster thread (R) | M27×2.0 |
| Port size | PT3/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M18×1.5 F / M26×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. Force is unchanged from a standard SDA of the same bore. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Force matches a standard SDA of the same bore; the adjuster only sets the stop position, not the area. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B Is Used
Heavy Press Fitment
Dial the 0-10 mm extend stop to precisely seat heavy bearings without over-traveling, leveraging the 3927 N push force for stubborn fits.
Short-Depth Clamping
Utilize the compact riveted body to squeeze high-force clamping into narrow machine cells where standard cylinders demand too much axial depth.
Changeover Positioning
Quickly readjust the extend endpoint on-site during product family changeovers, avoiding the downtime of mechanical shim swaps.
Is the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B the Right Cylinder?
When sizing this bore, step down to the SDAJ80 for lighter duties, which provides 2513.3 N push at 0.5 MPa, or step up if you exceed the 801 kgf maximum theoretical push at 1.0 MPa. This 100 mm bore yields a safe working load of roughly 2356 N, assuming a 60 percent safety margin of the 3927 N figure at 0.5 MPa, translating to a vertical lift capacity of about 200.2 kg with a 2:1 factor.
Choose this specific SKU if your fixture requires on-site extend tuning between 0 and 10 mm. Confirm your port is PT3/8 and that you need the male M26x1.5 rod end. Remember that a plain cylinder drifts when air is lost or the valve centers; the fixed bumper only decelerates near the end and is not a lock. For secure load holding without live pressure, install an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 0–10 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M27×2.0 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10B FAQ
At 0.5 MPa it provides 3927 N push and 3524.9 N pull. At 0.7 MPa it yields 5497.8 N push and 4934.8 N pull. The theoretical maximum push is 801 kgf at 1.0 MPa.
The R (M27x2.0) screw mechanically shortens the extend endpoint by up to 10 mm without changing the force. It is not a mid-stroke lock; the cylinder drifts on air loss. For load holding, use an external rod lock or pilot-operated check valve.
