Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S
The AirTAC Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S is a genuine double-acting COMPACT cylinder (Ø100mm bore) whose extend end-position is set by an external M27×2.0 adjustment screw. You can dial the stroke anywhere from 0 to 10 mm on the machine — no shims, no part change.
- BoreØ100 mm
- Max stroke10 mm
- Adjustable range0–10 mm
- Adjuster threadM27×2.0
- Port sizePT3/8
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S
The AirTAC SDAJ100X10-10S is a double-acting compact cylinder featuring an external adjustable extend stop. An M27x2.0 adjuster screw lets you dial the outward stroke from 0 to 10 mm directly on the machine, eliminating the need for shims or part swaps during commissioning. Because the mechanism only sets the mechanical stop position, output force remains identical to a standard SDA of this bore, delivering 3927 N push at 0.5 MPa.
Its short riveted body saves axial mounting depth where a round-body or profile cylinder will not fit. The unit relies on a fixed NBR bumper at each end to decelerate the stroke end; this is not an adjustable air cushion, so for high energy approaches you should add an external shock absorber. The built-in piston magnet supports AirTAC reed or electronic switches for position confirmation.
Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S Technical Specifications
| Model | Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S |
|---|---|
| Series | SDAJ compact adjustable-stroke cylinder |
| Bore size | Ø100 mm |
| Max stroke | 10 mm |
| Adjustable range | 0 – 10 mm |
| Adjuster thread (R) | M27×2.0 |
| Port size | PT3/8 |
| Acting type | Double acting |
|---|---|
| Rod end thread | M18×1.5 F / M26×1.5 male (B) |
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
The adjustment screw shortens the extend stroke by up to 10 mm. Force is unchanged from a standard SDA of the same bore. Specifications follow the official AirTAC SDAJ datasheet.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3525 N |
| 0.7 MPa | 5498 N | — |
| Max (@1.0 MPa) | 801 kgf | |
Force matches a standard SDA of the same bore; the adjuster only sets the stop position, not the area. Actual usable force is lower than theoretical due to friction.
Model Code: Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S
| SDAJ | Compact double-acting cylinder with adjustable stroke. |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Maximum stroke length in mm. |
| -10 | Adjustable window (10/20/30/40/50/75/100 mm). |
| S / B | S = magnet; B = male-thread rod (both optional). |
Thread: PT standard. Related SDA-family variants: SDA (fixed stroke), SDAD (double rod), SSA/STA (single acting), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S Is Used
Heavy Press Fit Tuning
Dial the 0-10 mm extend stop during press fit commissioning to find the exact seating depth for bearings without swapping physical shims.
High-Force Clamping Changeover
Leverage the 3927 N push at 0.5 MPa to secure heavy parts, adjusting the outward clamp position rapidly when switching between product variants.
Vertical Lift Positioning
Safely raise a 200.2 kg payload with a 2:1 margin, using the mechanical stop to set precise lift heights in compact vertical stations.
Is the Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S the Right Cylinder?
When sizing this actuator, compare its 3927 N push at 0.5 MPa against neighbouring bores. Stepping down, the SDAJ80 provides 2513.3 N at the same pressure; stepping up is not available as 100 mm is the largest bore in this compact family. This 100 mm option is ideal if you need maximum thrust within a tight footprint. A computed safe working load is roughly 2356 N (about 60 percent of the 0.5 MPa figure), allowing a vertical lift of approximately 200.2 kg with a 2:1 margin.
Choose this model for heavy setup-heavy lines requiring exact outward positioning. Confirm your parameters: 100 mm bore, 10 mm stroke, 10 mm window, PT3/8 port, built-in magnet (S), and female M18x1.5 rod thread. Note that a plain cylinder does not hold its load on air loss or valve centring; for load holding without live pressure, install an external rod lock or pilot-operated check valve.
Quick checklist
- ✓ Need on-machine stroke fine-tuning?
- ✓ Target position within 0–10 mm
- ✓ Force at your working pressure
- ✓ Access to reach the R adjuster
- ✓ Magnet (S) for sensors?
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Lock the M27×2.0 adjuster after setting the stroke.
- check Avoid side load on the piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDAJ80~100 Adjustable Super Slim Cylinder SDAJ100X10-10S FAQ
This 100 mm bore double-acting cylinder delivers 3927 N push and 3524.9 N pull at 0.5 MPa, or 5497.8 N push and 4934.8 N pull at 0.7 MPa. The theoretical maximum push is 801 kgf at 1.0 MPa. It operates between 0.15 and 1.0 MPa at speeds of 30-500 mm/s.
The M27x2.0 R screw shortens the extend stop by up to 10 mm, giving a usable outward range of 0-10 mm while retract remains full stroke. The included -S magnet works with AirTAC reed or electronic switches for position sensing. The adjuster is a mechanical stop, not a mid-stroke lock.
