Airtac SE125 Standard Cylinder SE125X1050S
The AirTAC Airtac SE125 Standard Cylinder SE125X1050S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø125mm bore and 1050mm stroke, PT1/2 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ125 mm
- Stroke1050 mm
- Port sizePT1/2
- Acting typeDouble acting
- Rod threadM27×2
- CushionAdjustable, 40 mm
About the Airtac SE125 Standard Cylinder SE125X1050S
The AirTAC SE125X1050S is a double-acting single-rod ISO 15552 profile cylinder engineered for heavy-duty pneumatic tasks, yielding a substantial 6136 N push force at 0.5 MPa. Its square extruded aluminum barrel omits external tie rods, yielding a flush, corrosion-resistant exterior that simplifies direct mounting on heavy machinery.
This unit includes a built-in magnet for non-contact position sensing using AirTAC CMSE reed or DMSE electronic switches. Because the stroke is 1050 mm, it is a non-standard made-to-order length exceeding the 1500 mm standard maximum for this bore, and its field-adjustable air cushioning at both ends allows technicians to precisely tune end-of-stroke deceleration for massive 1252 kgf loads.
Airtac SE125 Standard Cylinder SE125X1050S Technical Specifications
| Model | Airtac SE125 Standard Cylinder SE125X1050S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø125 mm |
| Stroke | 1050 mm |
| Acting type | Double acting |
| Port size | PT1/2 |
| Rod thread | M27×2 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 500 mm/s |
| Cushion | Adjustable, 40 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø125mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 6136 N | 5734 N |
| 0.7 MPa | 8590 N | — |
| Max (@1.0 MPa) | 1251 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE125 Standard Cylinder SE125X1050S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 125 | Bore size in mm. |
| ×1050 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE125 Standard Cylinder SE125X1050S Is Used
Automotive Tier-1 Press Ejection
Provides the 6136 N push force required to eject heavy stamped body panels from hydraulic presses, utilizing the 1050 mm stroke to clear the tooling area completely.
Palletizer Diverter Arm
Actuates a heavy-duty diverter arm on an end-of-line palletizer, relying on the built-in magnet and DMSE electronic sensors to confirm full extension over 1050 mm.
Injection Mold Platen Extraction
Extracts large molded plastic automotive bumpers from injection molding machines, where the adjustable air cushions absorb the kinetic energy of the 1252 kgf capacity drive.
Is the Airtac SE125 Standard Cylinder SE125X1050S the Right Cylinder?
Select this 125 mm bore when your application demands the highest standard thrust in the SE range, generating 6136 N of push at 0.5 MPa. If your load requirement is lighter, stepping down to the 100 mm bore provides 3927 N of push, while the 125 mm bore is the largest available in this series, meaning no larger standard option exists for higher force needs.
At 1050 mm of stroke, the 32 mm rod and rod-end thread M27x2 carry significant side-load leverage, making an external guide carriage strictly necessary to prevent rod-bearing bending and premature seal failure. Remember that the adjustable air cushion only decelerates the piston near the stroke end; it does not hold the load if air pressure drops, so specify a BSE rod lock for fail-safe holding. This unit is dimensionally interchangeable per ISO 15552, accepting standard mounting accessories and PT1/2 ports.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE125 Standard Cylinder SE125X1050S FAQ
This 125 mm bore cylinder provides 6136 N push and 5734 N pull at 0.5 MPa, 8590 N push at 0.7 MPa, and a maximum push of 1252 kgf at 1.0 MPa. It operates at a speed range of 30-500 mm/s.
Yes, the SE125X1050S is dimensionally interchangeable per ISO 15552 / VDMA 24562 standards. You can use it as a drop-in replacement for other ISO 15552 profile cylinders, retaining the same PT1/2 port and mounting footprint.
