Airtac SE32 Standard Cylinder SE32X25
2. Piston features specially-shaped bidirectional sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Square aluminum tube construction with tie-rodless design and superior corrosion resistance;
4. Smooth and adjustable cushioning mechanism for stable operation;
5. Comprehensive selection of cylinder sizes and mounting accessories for flexible configurations;
6. High-temperature resistant seals enable operational range of 0~150°C.
Category: Standard Cylinders , Brand: AIRTAC , Series: SE32
AirTAC SE32X25 Standard Cylinder Specifications
- Model: SE32X25
- Type: ISO 6432 standard double-acting cylinder
- Bore size: 32 mm
- Stroke: 25 mm (adjustable cushion)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 optional)
- Cushion type: Rubber buffer + adjustable cushion screw
- Mounting type: Basic (no built-in mount) with optional accessories
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 0.45 kg (bare cylinder), 0.52 kg with magnetic switch
- Dimensions:
- Total length (L): 146 mm (at mid-stroke)
- Body width (W): 48 mm (including mounting bosses)
- Height (H): 32 mm (barrel diameter)
- Piston rod thread: M10x1.25
- Standard accessories: Cushion seals, mounting nuts
- Optional: Magnetic switch (D-A93 series compatible)
A compact ISO-standard pneumatic cylinder featuring precision-machined aluminum construction with wear-resistant chromium plating. The SE32X25 delivers 78N thrust at 0.5MPa pressure (extending) and achieves cycle rates up to 1,200 RPM. Its dual adjustable cushioning system reduces end-impact noise below 75dB(A). The cylinder body features corrosion-resistant anodizing and supports vertical/horizontal installation.
- Packaging machinery ejection mechanisms
- CNC machine tool clamping devices
- Conveyor sorting gate actuators
- Automated assembly line positioning
- Textile machinery tension control
Installation note:
Lubricate with ISO VG32 hydraulic oil (non-detergent). For vertical mounting,
install rod-end down to prevent moisture accumulation. Maintain 0.3mm minimum
clearance between magnetic switch and ferrous materials.
| Property | Property Value |
|---|---|
| sku | SE32X25 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Piston Rod Material | Medium Carbon Steel |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | <25 mm> |
