Airtac SE80 Standard Cylinder SE80AX10S
The AirTAC Airtac SE80 Standard Cylinder SE80AX10S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 10mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke10 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX10S
The AirTAC SE80AX10S is a double-acting single-rod ISO 15552 profile cylinder engineered for high force in tight stroke applications, delivering 2513 N of push force at 0.5 MPa. It features a SUS420J2 stainless steel rod (code A) tailored for corrosive or washdown environments. The square extruded aluminum barrel omits external tie rods, yielding a compact, flush-mounting body that resists corrosion and simplifies fixture integration.
This specific configuration includes a built-in magnet (code S) for position sensing with AirTAC CMSE reed and DMSE electronic switches. Field-adjustable pneumatic cushioning at both ends allows you to tune end-of-stroke deceleration, softening hard impacts during rapid 30-800 mm/s cycling. The standardized ISO 15552 mounting interface ensures true dimensional interchangeability with other profile cylinders, streamlining retrofits.
Airtac SE80 Standard Cylinder SE80AX10S Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX10S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX10S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX10S Is Used
CNC Spindle Clamping
Uses the 2513 N push at 0.5 MPa to secure heavy cast iron housings during CNC machining, leveraging the 10 mm stroke for rapid actuation.
Bottling Line Diversion
Employs the SUS420J2 stainless rod to withstand caustic washdowns while using the built-in magnet to trigger DMSE sensors for sorting gate control.
Injection Mold Ejection
Relies on the field-adjustable cushion to soften the abrupt end stops inherent to short 10 mm strokes during rapid plastic part ejection.
Is the Airtac SE80 Standard Cylinder SE80AX10S the Right Cylinder?
Selecting the SE80AX10S is ideal when you need high clamping force within a very short 10 mm stroke, such as in compact machining centers. If you need to step the bore down, the 63 mm version offers 1559 N of push at 0.5 MPa, whereas stepping up to the 100 mm bore yields 3927 N at 0.5 MPa for heavier pressing. Because the stroke is only 10 mm, side-load stress on the rod bearing is minimal compared to longer strokes. Note that this standard cylinder does not hold its load when air is exhausted; if your process requires position holding without live pressure, consider the BSE rod-lock variant. For a drop-in replacement, match the 80 mm bore, 10 mm stroke, PT3/8 port, and your required mounting accessory.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX10S FAQ
The SE80AX10S delivers a push force of 2513 N and a pull force of 2268 N at 0.5 MPa. At 0.7 MPa, the push force is 3518 N, with a maximum push of 513 kgf at 1.0 MPa. The operating speed ranges from 30-800 mm/s.
Yes, the SE80AX10S is dimensionally interchangeable per ISO 15552, serving as a drop-in replacement for other standard profile cylinders. It is a double-acting cylinder and does not hold its load if air is lost; for position holding, an external rod lock or the BSE variant is required.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models usually ship in 3-4 days.
Fast Reply
Most inquiries answered within 7-8 hours.
Request a Quote for Airtac SE80 Standard Cylinder SE80AX10S
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
