Airtac SE80 Standard Cylinder SE80AX130
The AirTAC Airtac SE80 Standard Cylinder SE80AX130 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 130mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke130 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX130
The AirTAC SE80AX130 is a double-acting, single-rod ISO 15552 profile cylinder engineered for demanding environments. It delivers a robust 2513 N push force at 0.5 MPa, utilizing a 25 mm SUS420J2 stainless steel rod that resists corrosion and stands up to washdown cleaning. The extruded aluminum barrel design omits external tie rods, yielding a compact, flush-mounting body that simplifies sensor placement and prevents debris accumulation.
Unlike fixed rubber bumpers, this actuator features a field-adjustable air cushion at both ends, allowing technicians to tune end-of-stroke deceleration via a set screw to match varying 130 mm stroke speeds up to 800 mm/s. Because this specific SKU lacks a built-in magnet, it is not wired for CMSE or DMSE position sensing out of the box, serving purely as a robust mechanical drive.
Airtac SE80 Standard Cylinder SE80AX130 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX130 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX130
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX130 Is Used
Palletizer Case Pusher
Handles 130 mm repositioning strokes to push heavy corrugated cases onto palletizer lanes, utilizing the 2513 N force and SUS420J2 rod to withstand occasional washdowns in food-packing zones.
Press Brake Backgauge
Positions sheet metal flanges with precision during air bending, where the hard-chrome stainless rod resists coolant mists and the adjustable cushion softens rapid 800 mm/s reversals.
Bottling Line Diverter
Actuates a 130 mm routing gate to deflect bottles between labeling stations, relying on the smooth extruded profile to prevent water pooling during high-pressure caustic washdowns.
Is the Airtac SE80 Standard Cylinder SE80AX130 the Right Cylinder?
If 2513 N of push at 0.5 MPa is too much for your fixture, step down to the 63 mm bore, which yields 1559 N. If your payload requires more muscle, the 100 mm bore provides 3927 N at the same pressure. Keep in mind that a plain SE cylinder cannot hold a load if air pressure drops or the valve centers; the piston will drift. For position holding without live air, you need a BSE rod-lock variant or an external pilot-operated check valve. The PT3/8 port and M20x1.5 rod thread match standard ISO 15552 mounting hardware, making this a drop-in retrofit for existing tooling.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX130 FAQ
At 0.5 MPa, this 80 mm bore cylinder provides 2513 N of push force and 2268 N of pull force. At 0.7 MPa, the push force reaches 3518 N, with a maximum push capacity of 513 kgf at 1.0 MPa. It uses a PT3/8 port, a 25 mm SUS420J2 stainless steel rod with an M20x1.5 thread, and has a 36 mm cushion length.
Yes. The SE80AX130 is dimensionally interchangeable per ISO 15552 standards, meaning its mounting footprint and port locations align with other ISO 15552 profile cylinders. You can swap it directly into existing machinery using standard FA, FB, or TC mounting accessories without redesigning the machine frame.
