Airtac SE80 Standard Cylinder SE80AX130SH
The AirTAC Airtac SE80 Standard Cylinder SE80AX130SH is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 130mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke130 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX130SH
The AirTAC SE80AX130SH is a double-acting, single-rod ISO 15552 profile cylinder engineered for rigorous washdown and high-temperature environments. It delivers a robust 2513 N push force at 0.5 MPa (3518 N at 0.7 MPa) across a 130 mm stroke, utilizing a 25 mm diameter rod with an M20x1.5 thread. Because it features a SUS420J2 stainless steel rod and a Viton (FKM) seal, this configuration reliably operates in ambient temperatures up to 150 °C while resisting chemical corrosion.
The extruded aluminum barrel design omits external tie rods, yielding a smooth, compact body that mounts flush against machine frames without snagging. Integrated sensor grooves on three sides allow flexible placement of CMSE reed or DMSE electronic switches, capitalizing on the built-in magnet for precise end-of-stroke detection. Furthermore, the field-adjustable air cushions at both ends can be tuned via a set screw to smoothly decelerate heavy 80 mm payloads, preventing hard mechanical end-stop impacts at high cycle rates.
Airtac SE80 Standard Cylinder SE80AX130SH Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX130SH |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 130 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX130SH
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×130 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX130SH Is Used
Food Packaging Ejector
Leveraging the SUS420J2 stainless rod and Viton seal, this cylinder withstands high-temperature washdowns while pushing finished food cartons off a packaging line with 2513 N of force.
Injection Mold Extraction
The 130 mm stroke and high 3518 N push force at 0.7 MPa reliably extract heavy plastic automotive interior panels from hot injection molds, enduring ambient heat up to 150 °C.
Palletizing Clamp Arm
Operating a heavy-duty clamp mechanism on a robotic palletizer, the built-in magnet triggers DMSE electronic sensors to confirm grip status before pallet rotation begins.
Is the Airtac SE80 Standard Cylinder SE80AX130SH the Right Cylinder?
When sizing this 80 mm bore model, consider stepping down to a 63 mm cylinder (1559 N push at 0.5 MPa) for lighter loads, or up to a 100 mm bore (3927 N push at 0.5 MPa) if your application requires significantly more thrust. As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct drop-in replacement for other ISO 15552 profile cylinders, matching the 80 mm bore, 130 mm stroke, PT3/8 port, and standardized mounting hardware. Note that a plain SE cylinder relies on live air pressure to hold its load; if pneumatic pressure drops, the piston will drift. For fail-safe position holding, pair this with a BSE rod lock variant. Since the stroke is 130 mm, the 25 mm rod and rod-bearing handle side loads well, but for any extended unsupported strokes exceeding 300 mm, an external guide is recommended to prevent bending.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX130SH FAQ
This 80 mm bore cylinder provides 2513 N push and 2268 N pull at 0.5 MPa, 3518 N push at 0.7 MPa, and a maximum push force of 513 kgf at 1.0 MPa. It operates on filtered air at 0.15-1.0 MPa with a speed range of 30-800 mm/s.
Yes, the SE80AX130SH is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact same mounting footprint, 130 mm stroke, PT3/8 port, and M20x1.5 rod thread dimensions as other standard ISO 15552 profile cylinders for straightforward retrofits.
