Airtac SGD Series Steel Tube Type Double Rod Cylinder SGD160X25
2. SG Series features dual Y-type single-acting piston seals with automatic compensation, ensuring extended service life and low starting pressure. SGC Series adopts profiled dual-acting seal configuration for compact design and integrated oil reservoir capability;
3. SG Series utilizes cold drawn steel tubing construction with superior impact resistance;
4. SGC Series employs precision aluminum tubing with optional embedded sensor magnets (not compatible with SG Series);
5. Equipped with adjustable pneumatic cushioning mechanism for smooth deceleration control;
6. Comprehensive size range with multiple mounting accessories for flexible system integration;
7. Engineered with high humidity-resistant sealing compounds for operational temperature range of 0-150°C.
Category: Twin Shaft Cylinders | Brand: AIRTAC | Series: SGD
AirTAC SGD160X25 Steel Tube Type Double Rod Cylinder Specifications
- Model: SGD160X25
- Type: ISO 15552 compliant double rod cylinder
- Bore size: 160mm (±0.1mm honed finish)
- Stroke: 25mm (adjustable cushioning)
- Operating pressure: 0.15–1.0 MPa
- Rod diameter: 45mm (chromed steel, double-sided)
- Cushion type: Air cushion + external shock absorber
- Port size: G1/2 (standard), optional NPT1/2
- Temperature range: -20℃ to 80℃
- Seal material: HNBR/NOK seals (oil & heat resistant)
- Mounting: Basic MF1 flange, optional front flange/rear clevis
- Weight: 7.8kg (excluding accessories)
- Dimensions: 320mm(L) × 160mm(W) × 160mm(H) (at mid-stroke)
- Rod end threads: M20×1.5 (both ends)
- Max thrust: 11,300N @ 0.7MPa
- Piston speed: 50–700mm/s
Heavy-duty steel cylinder with twin hardened chrome rods for enhanced moment resistance. Features symmetrical force distribution and anti-rotation design, ideal for precision alignment tasks. Built-in magnetic slot (optional) for position sensing. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Press machine die positioning systems
- Automotive welding fixture clamping
- Sheet metal straightening equipment
- Plastic injection molding ejectors
- Bearing assembly precision pressing
Installation tip:
Use alignment jigs during mounting to prevent side load. Lubricate rods weekly with EP2 grease.
Maximum permissible lateral force: 220N at rod end. Avoid compressed air dew point below 3℃.
| Property | Property Value |
|---|---|
| sku | SGD160X25 |
| Seal Material | NBR |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Cushion Stroke | <50mm> |
| Bore Diameter | 160mm |
| Stroke | <25 mm> |
