Airtac SSA Single-Acting Compact Cylinder SSA16X10B
The AirTAC Airtac SSA Single-Acting Compact Cylinder SSA16X10B is a genuine single-acting COMPACT cylinder (single acting, push type) with a Ø16mm bore and 10mm stroke. Air pushes the rod and an internal spring returns it, so one solenoid line drives the motion — ideal for short-stroke clamping and ejection in tight spaces.
- BoreØ16 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeSingle acting, push type
- Rod threadM3×0.5 (F) / M5×0.8 (B)
- CushionFixed NBR bumper
About the Airtac SSA Single-Acting Compact Cylinder SSA16X10B
The AirTAC SSA16X10B is a compact single-acting push-type cylinder where air extends the rod and an internal spring retracts it. It provides 80.5 N of net push at 0.5 MPa, with the return spring force already subtracted for accurate sizing. This 16 mm bore unit uses a short riveted body to minimize axial mounting depth in crowded machinery.
This specific SKU features a male M5x0.8 piston rod thread and an M5x0.8 air port. Because it lacks the -S option, it has no piston magnet and cannot support position sensing. A fixed NBR bumper handles end-of-stroke deceleration, operating effectively at speeds between 50 and 500 mm/s.
Airtac SSA Single-Acting Compact Cylinder SSA16X10B Technical Specifications
| Model | Airtac SSA Single-Acting Compact Cylinder SSA16X10B |
|---|---|
| Series | SSA compact single-acting cylinder |
| Bore size | Ø16 mm |
| Stroke | 10 mm |
| Acting type | Single acting, push type |
| Port size | M5×0.8 |
| Rod end thread | M3×0.5 female / M5×0.8 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed NBR bumper |
| Max standard stroke | Up to 30 mm |
Specifications follow the official AirTAC SDA-family datasheet. Single-acting types start at 0.2 MPa (the spring must be overcome). Confirm against the product label before installation.
Net Output Force (Ø16mm, Push)
| Pressure | Push force (net) |
|---|---|
| 0.5 MPa | 81 N |
| 0.7 MPa | 121 N |
These are NET output forces — the return-spring force is already deducted. Single-acting push only; the spring performs the opposite stroke. Size with a safety margin.
Model Code: Airtac SSA Single-Acting Compact Cylinder SSA16X10B
| SSA | Compact single acting, push type cylinder series. |
|---|---|
| 16 | Bore size in mm. |
| ×10 | Stroke length in mm (single-acting max 30 mm). |
| S | Built-in magnet for magnetic-switch sensing (omit = none). |
| B | Male-thread piston rod (omit = female thread). |
Thread: PT standard. SSA pushes out / spring returns; STA pulls in / spring extends. Related: SDA (double acting), SDAD (double rod), SDAJ (adjustable stroke).
Where the Airtac SSA Single-Acting Compact Cylinder SSA16X10B Is Used
Small Part Ejection
Uses the 80.5 N net push to eject lightweight molded components from a tight fixture, saving axial depth with its compact riveted body.
Package Diverting
Employs the 10 mm stroke and male M5x0.8 rod to push small cartons on a conveyor, needing only one air line for simplified plumbing.
PCB Clamping
Applies under 48 N of safe clamping force to secure delicate circuit boards during assembly, relying on the fixed NBR bumper for gentle contact.
Is the Airtac SSA Single-Acting Compact Cylinder SSA16X10B the Right Cylinder?
When sizing this model, verify the 10 mm stroke and 16 mm bore meet your spatial limits. The net push is 80.5 N at 0.5 MPa, yielding a safe working load around 48 N or a vertical lift capacity of roughly 4.1 kg with a 2:1 margin. If less force is needed, the SSA12 offers 46.5 N; for more power, the SSA20 provides 134.1 N at the same pressure.
Confirm the male M5x0.8 rod thread suits your tooling and that no position sensing is required, as this unit lacks a magnet. Operating pressure must be 0.2-1.0 MPa to overcome the spring. Note that the spring actively retracts the rod on air loss, so it will not hold a mid-stroke load without external locking.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Stroke ≤ 30 mm (single-acting limit)
- ✓ Single air line saves a valve/port
- ✓ Magnet (S) for sensors?
- ✓ Female (blank) or male (B) rod thread
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Remember the spring performs the return stroke.
- check Avoid side load on the short piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SSA Single-Acting Compact Cylinder SSA16X10B FAQ
This single-acting push cylinder generates 80.5 N of net force at 0.5 MPa and 120.7 N at 0.7 MPa. These values already account for the internal return spring resistance.
No, this specific SKU does not include a piston magnet. You must select the -S variant to use AirTAC reed or electronic switches. Additionally, it requires at least 0.2 MPa to overcome the return spring.
