Airtac SSA Single-Acting Compact Cylinder SSA16X10SB
The AirTAC Airtac SSA Single-Acting Compact Cylinder SSA16X10SB is a genuine single-acting COMPACT cylinder (single acting, push type) with a Ø16mm bore and 10mm stroke. Air pushes the rod and an internal spring returns it, so one solenoid line drives the motion — ideal for short-stroke clamping and ejection in tight spaces.
- BoreØ16 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typeSingle acting, push type
- Rod threadM3×0.5 (F) / M5×0.8 (B)
- CushionFixed NBR bumper
About the Airtac SSA Single-Acting Compact Cylinder SSA16X10SB
The AirTAC SSA16X10SB is a compact single-acting push-type cylinder where air pressure extends the rod and an internal mechanical spring handles the retraction. Because it needs just one air line and a single solenoid port to drive the motion, you cut down on fittings and simplify valve requirements in crowded fixtures. This 16 mm bore unit provides 80.5 N of net push at 0.5 MPa, with the return spring force already subtracted from the raw air force.
This specific configuration includes a built-in piston magnet for AirTAC reed or electronic switches, plus a male M5x0.8 threaded rod end for direct mounting. The short riveted body saves valuable axial depth compared to standard round-body cylinders. A fixed NBR bumper absorbs end-of-stroke shock, and the unit operates at speeds between 50 and 500 mm/s.
Airtac SSA Single-Acting Compact Cylinder SSA16X10SB Technical Specifications
| Model | Airtac SSA Single-Acting Compact Cylinder SSA16X10SB |
|---|---|
| Series | SSA compact single-acting cylinder |
| Bore size | Ø16 mm |
| Stroke | 10 mm |
| Acting type | Single acting, push type |
| Port size | M5×0.8 |
| Rod end thread | M3×0.5 female / M5×0.8 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 500 mm/s |
| Cushion | Fixed NBR bumper |
| Max standard stroke | Up to 30 mm |
Specifications follow the official AirTAC SDA-family datasheet. Single-acting types start at 0.2 MPa (the spring must be overcome). Confirm against the product label before installation.
Net Output Force (Ø16mm, Push)
| Pressure | Push force (net) |
|---|---|
| 0.5 MPa | 81 N |
| 0.7 MPa | 121 N |
These are NET output forces — the return-spring force is already deducted. Single-acting push only; the spring performs the opposite stroke. Size with a safety margin.
Model Code: Airtac SSA Single-Acting Compact Cylinder SSA16X10SB
| SSA | Compact single acting, push type cylinder series. |
|---|---|
| 16 | Bore size in mm. |
| ×10 | Stroke length in mm (single-acting max 30 mm). |
| S | Built-in magnet for magnetic-switch sensing (omit = none). |
| B | Male-thread piston rod (omit = female thread). |
Thread: PT standard. SSA pushes out / spring returns; STA pulls in / spring extends. Related: SDA (double acting), SDAD (double rod), SDAJ (adjustable stroke).
Where the Airtac SSA Single-Acting Compact Cylinder SSA16X10SB Is Used
Small Part Ejection
Uses the 80.5 N net push to reliably eject small molded components from a tight fixture, relying on the internal spring to reset automatically.
Package Diverter
Employs the male M5x0.8 rod thread to mount a custom diverting flap that pushes light cartons on a conveyor within the 10 mm stroke range.
Light Duty Clamping
Secures thin workpieces during secondary machining, taking advantage of the compact riveted body to fit into low-clearance assembly jigs.
Is the Airtac SSA Single-Acting Compact Cylinder SSA16X10SB the Right Cylinder?
When sizing this model, evaluate your force needs against the 80.5 N net push available at 0.5 MPa. Stepping down to the SSA12 drops the output to 46.5 N, while moving up to the SSA20 increases it to 134.1 N. A safe working load is roughly 48 N, which allows a vertical lift of about 4.1 kg with a 2:1 safety margin. Keep in mind the 30 mm maximum stroke ceiling for this series.
Confirm the 16 mm bore, 10 mm stroke, M5x0.8 port, and the male M5x0.8 rod thread suit your tooling. Because the spring drives the rod back to rest upon air loss, this cylinder does not hold a mid-stroke load; use a double-acting SDA with an external rod lock if you require position holding without live pressure.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Stroke ≤ 30 mm (single-acting limit)
- ✓ Single air line saves a valve/port
- ✓ Magnet (S) for sensors?
- ✓ Female (blank) or male (B) rod thread
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 1.0 MPa operating pressure.
- check Remember the spring performs the return stroke.
- check Avoid side load on the short piston rod.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SSA Single-Acting Compact Cylinder SSA16X10SB FAQ
The net push force is 80.5 N at 0.5 MPa and 120.7 N at 0.7 MPa. These figures already account for the internal return spring resistance, giving you the true usable output for your design calculations.
No, the spring retracts the rod to its rest position when air is released, so it cannot hold a mid-stroke load. It also requires a minimum operating pressure of 0.2 MPa to overcome the spring and extend the rod.
