Airtac STWA Slide Table Cylinder STWA10X75S
Genuine AirTAC slide cylinder, order code STWA10X75S from the STW range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
- MountingPlate fixed (STWA)
- BoreØ10 mm
- Stroke75 mm
- ActionDouble acting, twin rod
- CushionHydraulic shock absorber
- Ø1050.3 N at 0.5 MPa · port M5×0.8
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac STWA Slide Table Cylinder STWA10X75S
Order code STWA10X75S selects the AirTAC STW slide cylinder fixed by its end plate, with a Dia 10 mm twin-rod body and a 75 mm stroke. The two rods share the moving and side loads, so the slide resists bending and twisting far better than a single-rod cylinder of the same size.
At 0.5 MPa the Dia 10 bore produces 50.3 N of theoretical force on a 0.2-1.0 MPa air supply filtered to 40 um. Piping is M5x0.8, and because the body carries three sets of ports you can feed air from whichever side suits the layout. Hydraulic shock absorbers slow both stroke ends, and the built-in magnet rides a sensor rail for position detection.
Airtac STWA Slide Table Cylinder STWA10X75S Technical Specifications
| Order code | STWA10X75S |
|---|---|
| Product | Slide Cylinder |
| Mounting | Plate fixed (STWA) |
| Bore | Ø10 mm |
| Stroke | 75 mm |
| Action | Double acting, twin rod |
|---|---|
| Cushion | Hydraulic shock absorber |
| Ø10 | 50.3 N at 0.5 MPa · port M5×0.8 |
| Ø16 | 122.5 N at 0.5 MPa · port M5×0.8 |
| Ø20 | 201.1 N at 0.5 MPa · port M5×0.8 |
| Ø25 | 289.8 N at 0.5 MPa · port PT1/8 |
| Ø32 | 490.1 N at 0.5 MPa · port PT1/8 |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.2-1.0 MPa (Ø10), 0.15-1.0 MPa (Ø16-32) |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Speed | 30-500 mm/s |
| Stroke tolerance | +1.0 / 0 mm (≤100), +1.5 / 0 mm (>100) |
| Anti-rotation | ±0.1° (Ø10), ±0.05° (Ø16, 20), ±0.03° (Ø25, 32) |
| Port | M5×0.8 (Ø10-20), PT1/8 (Ø25, 32) |
Source: AirTAC Products Catalog 2026A (PDF01-P0547..P0548), STW series specifications, theoretical force, strokes and ordering code.
How to choose
Pick STWA10X75S over STWB10 when your machine clamps the end plate rather than the cylinder body. The 75 mm stroke sits in the upper half of the Dia 10 stroke range of 25 to 100 mm, with a stroke tolerance of +1.0 / 0 mm. If 50.3 N is too little force, step up to the Dia 16 STWA16 codes for 122.5 N at 0.5 MPa.
Applications
Light pick-and-place
Side-load a small gripper with confidence: the twin-rod slide holds the plate within 0.1 degree of rotation while the Dia 10 bore gives 50.3 N at 0.5 MPa for light part transfer.
Stopper or reject pusher
Use the 75 mm stroke to stop or divert small products on a conveyor lane, with the built-in magnet reporting extended position to the PLC through the sensor rail.
Small fixture indexing
Advance small fixture pallets by 75 mm between assembly steps, with hydraulic shock absorbers cushioning both ends so the fixture sees no hard impact.
FAQ
What are the key figures of the STWA10X75S?
Plate-fixed STWA slide cylinder, Dia 10 mm bore, 75 mm stroke, double acting with twin rods. Theoretical force 50.3 N at 0.5 MPa, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), ports M5x0.8, speed 30-500 mm/s, temperature -20 to +70 C, air filtered to 40 um.
How do position sensing and piping work on this code?
Every STW version, including the STWA10X75S, carries a built-in magnet with a sensor mounting rail, so switches can detect end or mid-stroke positions; confirm the matching sensor from the datasheet. Three sets of M5x0.8 ports give a choice of piping direction, and slide anti-rotation is held within 0.1 degree.
