Airtac STWA Slide Table Cylinder STWA16X50S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA16X50S Slide Cylinder Specifications
- Model: STWA16X50S
- Type: Twin-shaft compact slide cylinder (double-acting)
- Bore size: 16mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.9 MPa
- Piston speed: 50–800 mm/s
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting: Standard MF1 (front flange) with 4x M4 threaded holes
- Material: Aluminum alloy body, hard anodized piston rod
- Seal material: NBR (nitrile) with grease retention design
- Temperature range: -10℃ to 80℃
- Weight: 0.62 kg (excluding accessories)
- Dimensions: 160mm(L) × 42mm(W) × 42mm(H)
- Rod diameter: 6mm (chrome-plated)
- Repeat positioning accuracy: ±0.1mm
- Lubrication: Pre-lubricated (maintenance-free for 2000km travel)
High-precision linear actuator with integrated guide mechanism, designed for space-constrained automation systems requiring precise positional control. Features dual stainless steel guide shafts (9mm diameter) with ball bushings for minimal friction and anti-rotation stability. Optional magnetic piston version (STWA16X50S-M) available for position sensing.
- PCB component insertion machines
- Laser marking equipment positioning stages
- Pharmaceutical blister packaging systems
- Semiconductor wafer handling robots
- Automated optical inspection (AOI) equipment
Installation note:
Ensure proper alignment of guide shafts during mounting (max 0.05mm/m parallelism tolerance).
Use compatible AirTAC SCM series mounting brackets for vibration-sensitive applications.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil in high-cycle operations.
| Property | Property Value |
|---|---|
| sku | STWA16X50S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | <50mm> |
