Airtac STWA Slide Table Cylinder STWA16X75S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA Series Slide Cylinder STWA16X75S Technical Details
- Model: STWA16X75S
- Type: Compact guided slide cylinder (dual-axis guide)
- Bore size: 16mm
- Stroke: 75mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Double bracket mounting (ISO 15552 compatible)
- Port size: M5x0.8 (G1/8 adapter optional)
- Piston material: Hard anodized aluminum alloy
- Rod material: Stainless steel SUS304
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.82kg (excluding accessories)
- Dimensions: 160mm(L) × 50mm(W) × 60mm(H)
- Max thrust: 31.4N at 0.5MPa
- Repeat positioning accuracy: ±0.05mm
- Protection rating: IP40 (dust protected)
Precision-guided slide cylinder with integrated linear guide rails, featuring zero rotational play and smooth SPT (Super Positioning Technology) movement. The dual-axis design ensures exceptional lateral load capacity (up to 2.5N·m moment resistance). Includes wear-compensation mechanism for extended service life. Lubrication-free operation with factory-preloaded grease.
- PCB component insertion machines
- Automated optical inspection (AOI) equipment
- Laser marking/cutting positioners
- Precision fixture clamping systems
- Pharmaceutical blister packaging lines
Installation guidelines:
Maintain 0.5-1mm clearance between mounting surface and cylinder base.
Use only angular misalignment ≤0.5° during alignment. For vertical installations,
recommend adding external shock absorbers at stroke ends.
| Property | Property Value |
|---|---|
| sku | STWA16X75S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 75mm |
