Airtac STWA Slide Table Cylinder STWA20X25S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA Series Slide Table Cylinder STWA20X25S Technical Details
- Model: STWA20X25S
- Type: Guided slide table cylinder with integrated linear guide
- Bore size: 20mm
- Stroke: 25mm
- Operating pressure: 0.05–0.7 MPa
- Cushioning: Adjustable air cushion (both ends)
- Mounting style: Side mounting holes + front flange
- Piston speed: 50–700 mm/s (optimal range)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (Nye Rhein NBU12/PTFE)
- Seal material: NBR + polyurethane hybrid seals
- Repeat accuracy: ±0.05mm
- Load capacity: 3.5N·m max moment (dynamic)
- Weight: 0.82kg (excluding accessories)
- Dimensions:
- Body length: 135mm
- Table width: 40mm
- Total height: 47mm (guide rail included)
- Mounting hole spacing: 30mm × 25mm
Precision-engineered slide cylinder combining pneumatic actuation with linear guidance, featuring ultra-low friction (<0.006 dynamic friction coefficient) for smooth reciprocating motion. The anodized aluminum construction with chrome-plated piston rod resists corrosion in industrial environments. Integrated T-slot table allows direct mounting of workpieces or tooling plates.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer handling systems
- Automated screw driving stations
- Medical device assembly with cleanroom compatibility
Installation guidelines:
Align cylinder axis within ±0.2mm perpendicularity tolerance. Use M4×8mm mounting screws (2N·m torque limit).
For vertical installations, add mechanical brake if load >1kg. Lubricate guide rails every 500km travel distance.
| Property | Property Value |
|---|---|
| sku | STWA20X25S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
