Airtac STWA Slide Table Cylinder STWA20X50S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA20X50S Slide Table Cylinder Specifications
- Model: STWA20X50S
- Type: Compact slide table cylinder with integrated guide
- Bore size: 20mm
- Stroke: 50mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Mounting style: Through-hole (M4×0.7) & front flange options
- Port size: M5×0.8 (standard) or NPT1/8 (optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy body, hardened steel guide rods
- Seals: NBR (standard) / PU (optional)
- Weight: 0.85kg (with standard accessories)
- Dimensions: 200mm(L) × 42mm(W) × 42mm(H)
- Rod end thread: M6×1.0 internal thread
- Repeat positioning accuracy: ±0.05mm
- Max lateral load: 9.8N
- Protection rating: IP40 (dust protected)
Precision-guided slide cylinder combining pneumatic actuation with linear bearing stability. Features dual-shaft anti-rotation design and wear-resistant anodized surface. The T-slot mounting surface allows modular accessory attachment. Requires 5μm filtered lubricated air (ISO8573-1 class 3-4-3).
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Semiconductor wafer handling systems
- Automated screw driving units
- Micro-dispensing robot arms
Installation note:
Align guide shafts parallel to mounting surface within 0.1mm/m tolerance.
Apply lithium soap-based grease to guide rails every 500km of travel.
- Max speed: 700mm/s (with cushioning)
- Lubrication interval: Every 3 months or 2,000km travel
- Breakaway pressure: ≥0.08MPa
| Property | Property Value |
|---|---|
| sku | STWA20X50S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | <50mm> |
