Airtac STWA Slide Table Cylinder STWA25X75S
2. Triple air ports (inlet/outlet) configuration provides flexible piping options;
3. Double piston rod structure ensures superior bending resistance and torsional rigidity, capable of withstanding heavy dynamic loads and lateral forces;
4. Integrated oil-cushioned shock absorbers effectively mitigate impact velocity, extending operational lifespan.
Category: Slide Table Cylinder | Brand: AirTAC | Series: STWA
AirTAC STWA Slide Cylinder STWA25X75S Technical Specifications
- Model: STWA25X75S
- Bore size: Ø25mm
- Stroke: 75mm (±0.5mm tolerance)
- Mounting type: Dual rectangular guide block
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Piston speed: 50–800 mm/s (optimal range)
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Body material: Anodized aluminum alloy (AL6063)
- Seal material: Nitrile rubber (NBR) + Polyurethane (PU)
- Guide mechanism: Linear ball bearing system
- Repeat positioning accuracy: ±0.05mm
- Weight: 1.8 kg (without accessories)
- Dimensions: 190mm(L) × 54mm(W) × 42mm(H)
- Protection rating: IP54 (standard sealing)
- Lubrication: Pre-lubricated (maintenance-free for 2000km travel)
Precision-guided slide cylinder with integrated linear rails, designed for high-accuracy positioning in automated systems. Features dual-axis alignment correction and wear-resistant polymer scrapers to prevent particulate ingress. The hardened steel guide shafts (HRC60+) ensure minimal deflection under side loads up to 120N.
- PCB component insertion machines
- Lens coating automation systems
- Pharmaceutical blister packaging
- Semiconductor wafer handling
- Automotive part testing jigs
- 3D printer Z-axis stabilization
Installation recommendation:
Mount on machined surface with flatness ≤0.1mm/m. Use 4x M5 screws (8.8 grade min.)
torqued to 3.5N·m in cross pattern. Align air ports downward for condensate drainage.
| Property | Property Value |
|---|---|
| sku | STWA25X75S |
| Mounting Type | Fixed Plate Mounting Type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <25 mm> |
| Stroke | 75mm |
