Airtac STWB Slide Table Cylinder STWB10X25S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Cylinder STWB10X25S Specifications
- Model: STWB10X25S
- Type: Compact guided slide cylinder (single-axis)
- Bore size: 10mm
- Stroke: 25mm (±0.5mm tolerance)
- Operating pressure: 0.05–0.7 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Structure material: Aluminum alloy cylinder, SUS304 piston rod
- Seal material: NBR (nitrile rubber)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s (with cushioning)
- Mounting options: Side mounting holes (M4×0.7×6mm deep)
- Weight: 0.35kg (without accessories)
- Dimensions: 145mm(L) × 30mm(W) × 30mm(H) (full extension)
- Temperature range: -20℃ to 80℃
- Lubrication: Pre-lubricated (use ISO VG32 hydraulic oil)
- Built-in sensor slot: M5 slot for proximity switch
- Protection rating: IP54 (standard), IP67 optional
A precision linear motion solution combining cylinder and guide mechanism in one compact unit. Features low-friction dual linear ball bearings for smooth movement and anti-rotation stability. The anodized surface treatment enhances corrosion resistance in humid environments. Ideal for applications requiring precise positioning and minimal deflection.
- PCB component insertion machines
- Laser marking/engraving positioners
- Semiconductor wafer handling systems
- Automated optical inspection (AOI) equipment
- Medical device assembly lines
- 3D printer Z-axis mechanisms
Installation tips:
Align guide rail parallelism within 0.05mm during mounting. Use torque-controlled screws (0.8-1.2N·m for M4) to prevent frame deformation. For vertical installations, add a counterbalance valve when handling loads over 0.5kg.
| Property | Property Value |
|---|---|
| sku | STWB10X25S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <25 mm> |
