Airtac STWB Slide Table Cylinder STWB10X50S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB10X50S Slide Table Cylinder Specifications
- Model: STWB10X50S
- Type: Dual-axis guided cylinder with slide table
- Bore size: 10mm
- Stroke: 50mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable rubber buffers at both ends
- Piston rod thread: M5×0.8 (both ends)
- Table dimensions: 50mm(L) × 30mm(W)
- Material: Aluminum alloy body, hardened steel guide rods
- Seal type: NBR seals with grease lubrication
- Temperature range: -10℃ to 80℃
- Weight: 520g ±5%
- Overall dimensions: 120mm(L) × 30mm(W) × 24mm(H)
- Mounting: Standard M4 threaded holes (4 places)
- Repeat positioning accuracy: ±0.05mm
- Max lateral load: 2.5N·m
- Optional accessories: Magnetic switch (D-A93 series compatible)
Precision linear motion solution combining pneumatic cylinder and linear guide in one compact unit. Features dual chrome-plated steel shafts with preloaded ball bushings for minimal play and high moment resistance. Integrated T-slot table allows direct mounting of workpieces or tooling plates. Lubrication-free operation with built-in wipers to prevent contamination.
- PCB component insertion machines
- Micro-dispensing systems for adhesives
- Optical lens positioning stages
- Semiconductor wafer handling
- Automated test probe positioning
- Precision labeling equipment
Installation tip:
For optimal performance, align cylinder axis within 0.2mm parallel to motion direction.
Use shim washers when mounting to prevent guide rail deformation. Lubricate guide shafts
with ISO VG32 hydraulic oil if used in high-cycle (>5M cycles) applications.
| Property | Property Value |
|---|---|
| sku | STWB10X50S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <10mm> |
| Stroke | <50mm> |
