Airtac STWB Slide Table Cylinder STWB16X100S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB16X100S Linear Guide Slide Cylinder Specifications
- Model: STWB16X100S
- Type: Compact slide cylinder with linear guide
- Bore size: 16mm
- Stroke: 100mm (customizable 10-300mm)
- Mounting style: Base-mounted with through holes
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable elastic buffers at both ends
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s (with cushioning)
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports at both ends)
- Seal material: Heat-resistant NBR/PU
- Protection rating: IP54 (dust & splash resistant)
- Guide mechanism: Dual linear ball bearings
- Rail length: 160mm (fixed for 100mm stroke)
- Lubrication: Pre-lubed (Grease maintenance interval: 2,000km)
- Weight: 0.75kg (excluding mounting accessories)
- Dimensions: 196mm(L) × 42mm(W) × 34mm(H)
Precision-guided pneumatic slide cylinder combining smooth linear motion with exceptional load capacity (1.2kN radial/0.8kN lateral). Features integrated T-slot mounting grooves and corrosion-resistant aluminum alloy body. Requires 40μm filtered air with 1-10% lubricant oil mist ratio for optimal performance.
- CNC tool changers and auto-feed mechanisms
- 3D printer Z-axis positioning systems
- Laser cutting nozzle height adjustment
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
Installation note:
Maintain horizontal mounting tolerance within ±0.1mm/m. For vertical installations,
use auxiliary support brackets and reduce max speed by 30%. Allow 0.5mm thermal
expansion clearance per meter during high-cycle operations.
| Property | Property Value |
|---|---|
| sku | STWB16X100S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 100mm |
