Airtac STWB Slide Table Cylinder STWB16X150S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB16X150S Guided Slide Cylinder Specifications
- Model: STWB16X150S
- Type: Twin-shaft guided slide cylinder (double-acting)
- Bore size: 16mm
- Stroke: 150mm (±0.5mm precision)
- Operating pressure: 0.1–0.9 MPa
- Piston speed: 50–800 mm/s (lubricated)
- Mounting style: Side-mount with 4x M4 threaded holes
- Rod material: Stainless steel SUS304
- Body material: Anodized aluminum alloy
- Cushioning: Adjustable rubber buffers (both ends)
- Position detection: Compatible with magnetic sensors (M9 connector)
- Temperature range: -20℃ to 80℃
- Weight: 0.58 kg (excluding accessories)
- Dimensions: 212mm(L) × 42mm(W) × 32mm(H) (fully retracted)
- Rod end: M6x1.0 internal thread
- ISO standard: 6432 (modified design)
- Repeat positioning accuracy: ±0.02mm
High-rigidity linear actuator with dual guide rods for precision linear motion. Features anti-rotation design and low-friction seals (NBR/SIC combination) for smooth operation. Includes built-in shock absorbers to minimize end-impact noise below 75dB. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- CNC machine tool chip conveyors
- Automated optical inspection (AOI) positioning stages
- Semiconductor wafer handling systems
- Pharmaceutical blister packaging machines
- 3D printer Z-axis drive mechanisms
Installation note:
Align guide rods within 0.1mm/m parallelism tolerance. Use only counterbored mounting screws (max protrusion 2mm below base). For vertical installations, reduce payload by 30% from horizontal rating.
| Property | Property Value |
|---|---|
| sku | STWB16X150S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 150mm |
