Airtac STWB Slide Table Cylinder STWB16X175S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB16X175S Slide Table Cylinder Specifications
- Model: STWB16X175S
- Type: Guided rod slide table cylinder (double-acting)
- Bore size: 16mm
- Stroke: 175mm ±0.5mm tolerance
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting options: Side mounting (Standard) / Bottom mounting via 4x M4 threaded holes
- Port size: M5x0.8 (Dual ports on both ends)
- Piston material: Aluminum alloy hard anodized
- Rod material: Stainless steel SUS304
- Seal material: NBR + Polyurethane
- Temperature range: -10℃ to 80℃
- Max lateral load: 6.5N·m
- Max moment load: 4.8N·m
- Weight: 1.2kg ±5% (Without accessories)
- Dimensions:
- Body length: 216mm (Including mounting brackets)
- Table width: 34mm
- Overall height: 40mm
- Center-to-center guide spacing: 30mm
Precision-guided pneumatic slide cylinder with integrated linear guides, offering exceptional rigidity and alignment accuracy. Features dual adjustable shock absorbers for smooth end-of-stroke deceleration. The T-slot table surface (34×8.5mm groove) allows modular fixture attachment. Requires ISO 8573-1 class 3 lubricated or non-lubricated air.
- PCB component insertion machines
- Lens polishing equipment positioning stages
- Automated screw driving stations
- Precision label application systems
- Semiconductor wafer handling
Installation guidelines:
Maintain 0.05mm/mm parallelism between guide rails and motion axis.
Apply lithium soap-based grease every 500km of travel.
Maximum permissible side load decreases by 30% when using bottom mounting configuration.
| Property | Property Value |
|---|---|
| sku | STWB16X175S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Stroke | 175mm |
