Airtac STWB Slide Table Cylinder STWB20X125S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB20X125S Slide Table Cylinder Specifications
- Model: STWB20X125S
- Type: Guided slide table with integrated cylinder (dual rail)
- Bore size: 20mm
- Stroke: 125mm
- Table dimensions: 72mm(W) × 52mm(H)
- Overall length: 231mm (stroke-dependent)
- Rod diameter: 10mm
- Operating pressure: 0.1–0.8 MPa
- Max thrust: 63N @ 0.5MPa
- Cushioning type: Adjustable rubber buffers
- Seal material: NBR/PU combination
- Temperature range: -20℃ to 80℃
- Weight: ~1.8kg (without accessories)
- Mounting: Horizontal/vertical via 4x M5 threaded holes
- Repeat positioning accuracy: ±0.05mm
- Max sliding speed: 500mm/s
- Protection rating: IP54 (standard)
- Sensor compatibility: M9 connector slots for magnetic switches
Precision-guided slide cylinder combining linear guide rails with pneumatic actuation. Features hardened steel shafts with chrome plating and aluminum alloy table. Integrated T-slot design allows direct mounting of workpieces/jigs. Low-friction seals enable smooth reciprocating motion with minimal stick-slip effect.
- PCB component insertion machines
- Automated sorting & positioning systems
- Lens polishing equipment linear stages
- Precision fixture clamping mechanisms
- 3D printer bed adjustment systems
Installation tips:
Align guide rails parallel to machine base using precision level (≤0.05mm/m tolerance).
Apply lithium soap-based grease to guide shafts during maintenance.
Use vibration-proof nuts for payloads exceeding 2kg.
- Total width (rail center distance): 36mm
- Mounting hole pattern: 60mm × 25mm
- Table surface flatness: 0.02mm/m
- Rod thread: M10×1.25
| Property | Property Value |
|---|---|
| sku | STWB20X125S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
