Airtac STWB Slide Table Cylinder STWB20X175S
2、Three sets of air inlet/outlet ports facilitate versatile piping configuration;
3、Dual piston rod design enhances bending resistance and torsional rigidity, enabling superior load-bearing capacity for dynamic and lateral forces;
4、Integrated hydraulic shock absorbers effectively mitigate impact velocity, optimizing cylinder durability.
Category: Slide Table Cylinders, Brand: Airtac, Series: STWB
AirTAC STWB Series Slide Table Cylinder STWB20X175S Specifications
- Model: STWB20X175S
- Bore size: 20mm
- Stroke: 175mm (±0.5mm tolerance)
- Structure: Twin-shaft slide table with integrated guide
- Mounting type: Front flange (standard)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Seal material: NBR + Special polyurethane alloy
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (dual ports on both ends)
- Repeat positioning accuracy: ±0.01mm
- Max speed: 500mm/s (with cushioning)
- Rod material: Hard chrome-plated steel
- Weight: 1.85kg (excluding accessories)
- Dimensions: 296mm(L) × 52mm(W) × 43mm(H)
- Protection class: IP54 (standard)
Precision-engineered slide cylinder with integrated linear guide rails, designed for high-accuracy linear motion applications. Features anti-rotation mechanism through dual guide shafts and pre-loaded ball bearings for minimal backlash. The hardened aluminum body with chrome-plated shafts ensures durability in continuous operation environments.
- Semiconductor wafer handling systems
- PCB component insertion machines
- Automated optical inspection (AOI) equipment
- Laser marking positioning stages
- Pharmaceutical blister packaging lines
- Robotic end-effector tooling
Installation guidelines:
Maintain perpendicularity within 0.05mm/m during mounting. Lubricate guide shafts with ISO VG32 hydraulic oil before initial operation. For vertical installations, use auxiliary support brackets when stroke exceeds 150mm.
- Max lateral load: 12N
- Max moment load: 3.5N·m
- Lubrication interval: Every 100km of travel or 6 months
- Breakaway pressure: ≤0.03MPa
| Property | Property Value |
|---|---|
| sku | STWB20X175S |
| Mounting Type | Body fixed type |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 175mm |
